National Instruments 782364-01 Automatic VNA Calibration Kit
Part number 782364-01 is an Automatic VNA Calibration Kit from National Instruments. This Calibration Accessory can be employed for the calibration of single-port and multi-port Vector Network Analyzers, including the PXIe-5630 (6 GHz) and PXIe-5632 (8 GHz). Part number 782364-01 is designed for male-female, K-type configuration. The operating frequency range of this device is 70 kHz to 9 GHz. VNA calibration kits perform the vital task of calibrating the VNAs right before they proceed to test.
Part number 782364-01 comes with an integrated calibration mechanism that sets a reference value for the analyzer. This calibrator can be deployed between the analyzer and the DUT. Since it is an Automatic Calibration Kit, part number 782364-01 does not require manual intervention or configuration. A K-type line is required for connecting PORT 1 of the VNA to the input port of the K-type calibration device. You will be able to characterize the errors of your network analyzer system in-house through this calibration kit.
The 782364-01 Calibration Kit is no longer available from Naitonal Instruments, but it will remain available in perpetuity with Apex Waves for both purchase and repairs!
| Model | 782364-01 |
|---|---|
| Manufacturer | NI |
| Type | Automatic VNA Calibration Kit |
| Compatible Models | PXIe-5630 and PXIe-5632 |
| Connection Type | K-Type, Male-Female |
| Frequency Range | 70 KHz to 9 GHz |
| Warranty | 2-3 Year Warranty |
| 782364-01 Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
Associated part numbers for 782364-01:
National Instruments 782364-01 Frequently Asked Questions
Question: What modules is the 782364-01 Calibration Kit compatible with?
Answer: The Calibration Kit is an optional accessory for both the PXIe-5630 and the PXIe-5632 VNAs.
Question: What is a K-type connector?
Answer: A k-type connector is designed specifically for thermocouple connections.
Question: What type of connections does the 782364-01 have?
Answer: The VNA Calibration Kit is equipped with connections for calibrating both male and female test ports.
