National Instruments AT-FBUS Foundation Fieldbus Device

The AT-FBUS is a Foundation Fieldbus Device manufactured by National Instruments. The NI AT-FBUS is constructed with part number 777281-01. The AT-FBUS is linked with the NI-FBUS software package. This device has a transformer-isolated fieldbus connection. The NI AT-FBUS is compatible with Windows 2000/NT/XP. This device can be used with the FP-3000 Fieldbus I/O Controller and a Fieldbus benchtop power supply co create a minimal Fieldbus control system.

The NI AT-FBUS is a removable interfacing device that is used to communicate between the network-configurable device and a personal computer. The network-configurable device is related to Foundation Fieldbus H1 protocols. The 16-bit ISA slot is used in PCs for communication purposes. The AT-FBUS is designed in a way that it can provide shared memory options. The NI AT-FBUS is built for a transfer rate up to 31.25 Kb/s associated with H1 specifications.

This device can be used with NI-FBUS Configurator software, as well as LabVIEW and Lookout. NI-FBUS CM can be utilized for numerous multithreaded applications and other processes. There are two types of AT-FBUS devices based on the number of ports. The AT-FBUS contains only one port for communication. The Fieldbus Device fabricated with two ports is represented as AT-FBUS/2. The NI AT-FBUS is equipped with a DB-9 male D-SUB input/output connector. Each pin is associated with one Fieldbus link. This device utilizes an Intel 80386EX microprocessor for the fieldbus communications software. The fieldbus interface chip is a Yamaha YTZ420. The typical current of the AT-FBUS Foundation Fieldbus Device is 750 mA and the maximum current is 850 mA.

ModelAT-FBUS
ManufacturerNational Instruments
Part Number777281-01
SeriesAT Series
TypeFoundation Fieldbus Device
Ports1
ProcessorIntel 80386EX
Fieldbus Interface ChipYamaha YTZ420
Driver SoftwareNI-FBUS Communications Manager
I/O ConnectorDB-9 male per fieldbus link
Dimensions4.2 by 7.5 in.
Warranty2-3 Year Warranty
AT-FBUS ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
