National Instruments NI-9246 C Series Current Input Module
Featured with 50 kS/s/ch sample rate, the National Instruments NI-9246 (Part number: 783920-01) is a 3-Channel, 24-Bit Current Input Module. This model offers direct ring lug connectivity to 3-phase high-current measurements of 1 and 5 Ampere current transformers (CTs). Moreover, the NI-9246 is optimized for energy, power, and industrial applications. The ±30 A peak input range and safety features incorporated in the module make it a versatile, suitable solution for challenging applications, such as power quality metering, substation merging units, utility pole-mounted smart switches and smart grid reclosers, predictive maintenance, health monitoring, and phasor measurement units (PMUs).
The NI-9246 is offered with Ring Lug Connectors that are suitable for up to 10 AWG cables. This module also offers up to 480 Vrms Channel-to Channel and 300 Vrms Channel-to-Earth CAT III isolation. This module can be considered for industrial applications where AC measurements up to 22 Arms are required. The three analog input channels of the National Instruments NI-9246 Current Input Module support AC coupling. Individual design elements incorporated in this module assist in ensuring an input noise as low as 0.25 mArms. In its default configuration, the NI 9246 is offered with a high voltage backshell and 6 ring lugs.
This Current Input Module comes equipped with a dedicated, Delta-Sigma ADC on each of the three analog input channels. The National Instruments NI-9246 features built-in protection against overcurrent that actuates when the device counters 50 Arms continuously or 100 Arms for 10 seconds and 1250 Arms for 1 cycle.
| Model | NI-9246 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 783920-01 |
| Type | C Series Current Input Module |
| Differential Analog Input Channels | 3 |
| Maximum Sample Rate | 50 kS/s per channel |
| Analog Input Resolution | 24 bits |
| Front Connector | Ring Terminals |
| Weight | 8.75 oz. |
| Warranty | 2-3 Year Warranty |
| NI-9246 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for NI-9246:
National Instruments NI-9246 Frequently Asked Questions
Question: What is the input noise of the NI 9246?
Answer: The input noise of the NI 9246 is 0.25 mArms.
Question: Does the NI-9246 work for one-phase current measurements?
Answer: Yes, the NI-9246 will work for one-phase and three-phase measurements.
Question: Which accessories are needed for operation of the NI 9246?
Answer: To operate the NI 9246, the user needs the Screw Terminal Strain Relief and Operator Protection for the NI 9246. Insulated Ring Terminals (12 to 10 AWG) and Extra Terminal Screws are optional.
Question: Which driver is required for the NI-9246 module?
Answer: The NI-9246 module requires NI-DAQmx version 15.1 or later to be calibrated.
