Q: What is the CAN supply voltage range of the NI 9882 module?

The CAN supply voltage range of the NI 9882 module is +9 to +30 VDC.

Q: Which type of power supply should be utilized with the NI-9882?

The NI-9882 should be utilized with a UL listed ITE power supply marked LPS.

Q: What is the power consumption from the chassis for the NI 9882?

The power consumption from the chassis for the NI 9882 is 1 W maximum in active mode and 2.55 mW maximum in sleep mode.

Q: Does the NI-9882 require any accessories?

Yes, the NI-9882 requires a CAN cable. There are several options to choose from: cables that are 1 or 2 m in length, with or without power terminals, High-Speed/FD or High-Speed/FD/Low-Speed, and with single termination or no termination.

NI-9882, 1-Port, High-Speed C Series DeviceNet Interface Module

Rated 4.8/5 | 17 ratings

NI-9882 National Instruments DeviceNet Interface Module | Apex Waves | Image

❮ ❯

Actual item may vary if no part number is provided on quote request.

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Anonymous Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

Name*

Email Address*

Model Name

Part Number

Qty

+Add more parts

Additional Info - Calibration, Expedited Shipping or Other Notes

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to: 1-919-809-5227

Carol Zimme**** Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

National Instruments NI-9882 C Series DeviceNet Interface Module

The National Instruments NI-9882 (Part Number: 781674-01) is a 1-Port, DeviceNet Interface Module. This high-speed DeviceNet Interface Module is designed to support the development of applications on CompactRIO hardware for DeviceNet drivers with the NI-Industrial Communications. DeviceNet is CAN physical layer oriented and boosts interconnectivity and strength by specifying numerous parameters, including but not limited to, the connectors, baud rates, and required cable length. For PCI devices, PXI modules, and the CompactRIO module, this module comes featured with a common API.

The National Instruments NI 9882 comes with one CAN port that operates in complete isolation from other modules existing in the system. This device can easily be connected to any location on a CAN bus through its port. The port incorporated in this module features a Bosch DCAN controller that is fully compatible with the CAN 2.0B and supports both 11 and 29-bit identifiers. Moreover, the CAN port of the NI-9882 also has a High-Speed, ISO 11898 compatible CAN transceiver (NXP PCA82C251T) that supports up to 1 Mbps baud rates.

This module offers +9 to +30 VDC CAN Supply voltage range (Vsup). While operating in inactive and sleep mode, the National Instruments NI-9882 DeviceNet Interface Module consumes 1 W and 2.55 mW of maximum power respectively. This 144 gram module offers up to 60 VDC Port-to-earth ground isolation (continuous). The user is allowed to apply -27 to +40 VDC max volts between Vsup terminals or any port and a COM terminal.

Model	NI-9882
Manufacturer	National Instruments
Part Number	781674-01
Type	C Series DeviceNet Interface Module
Ports	1
Maximum Baud Rate	1 Mbps
Transceiver	NXP PCA82C251T
CAN Supply Voltage Range	+9 to +30 VDC
Weight	5.0 oz.
Warranty	2-3 Year Warranty
NI-9882 Manual	User Manual and Maintenance Manual Available for Download
Price	Contact a sales representative for a quote.

Associated part numbers for NI-9882:

National Instruments NI-9882 Frequently Asked Questions

Question: What is the CAN supply voltage range of the NI 9882 module?

Answer: The CAN supply voltage range of the NI 9882 module is +9 to +30 VDC.

Question: Which type of power supply should be utilized with the NI-9882?

Answer: The NI-9882 should be utilized with a UL listed ITE power supply marked LPS.

Question: What is the power consumption from the chassis for the NI 9882?

Answer: The power consumption from the chassis for the NI 9882 is 1 W maximum in active mode and 2.55 mW maximum in sleep mode.

Question: Does the NI-9882 require any accessories?

Answer: Yes, the NI-9882 requires a CAN cable. There are several options to choose from: cables that are 1 or 2 m in length, with or without power terminals, High-Speed/FD or High-Speed/FD/Low-Speed, and with single termination or no termination.
