National Instruments NI-9997 C Series Busbar Module

Featured with CAT II, Channel-to-Channel isolation, the NI-9997 (Part Number: 783608-01) is a Busbar Module from National Instruments C Series. This module allows the routing of external excitation to both sensors and modules. The NI 9997 is designed to prevent your system from being affected by debris and dust in industrial settings where a polluted environment remains an issue. However, this module does not offer external connectivity with the backplane of the chassis.

The NI-9997 comes with 2 channels. Each channel has a capacity of up to 11 amperes of maximum current. In addition to two isolated channels, the NI-9997 also has 6 terminal channels. For screw terminals, you can use a 30 AWG to 14 AWG wire with a strip length of 6 millimeters. To attach more than one wire per screw terminal you can use a 2-wire ferrule.

The National Instruments NI-9997 C Series Busbar Module also supports the powering of multiple devices through a single, external power supply. Moreover, you can also use this module to connect various C Series modules to the common of the module. With this C Series Busbar Module, you can enjoy a simplified wiring experience where multiple shields or common pins need to be connected to a common ground.

This C Series Busbar Module is designed to withstand harsh temperature conditions. You can deploy this module in scenarios where the ambient temperature remains within -40 °C to 70 °C. However, the installation of this the NI 9926 inside a properly sealed panel is recommended. The NI-9997 is a Category II rated module and thus cannot be subjected to voltages greater than 60 VDC.

ModelNI-9997
ManufacturerNational Instruments
Part Number783608-01
SeriesC Series
TypeBusbar Module
Channels2 isolated, 6 terminal channels
Current per Channel11 A, maximum
Weight4.8 oz.
Warranty2-3 Year Warranty
NI-9997 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
