National Instruments cDAQ-9133 CompactDAQ Controller
The cDAQ-9133 (Part numbers: 783686-01 and 783687-01) is an eight-slot CompactDAQ Controller by National Instruments. This model is embedded with a Dual-Core Atom E3825 processor and has the frequency up to 1.33 GHz. The device is supported with Windows 7 and NI Linux Real-Time. The module has 2 Ethernet ports attuned with IEEE 802.3. The device has the communication rate from 10 Mbps, 100 Mbps, or 1000 Mbps, to auto-negotiated. The NI cDAQ‑9133 helps controls the timing and synchronization and helps transfer data between C Series I/O modules and a unified computer.
The NI cDAQ‑9133 Controller includes 16 GB of nonvolatile storage, which is used for embedded monitoring and data logging. The data transfer rate from a system to the removable card is 10 MB/s. The device offers a variety of standard expansion and connectivity options, which includes an RS-232 serial port with the maximum baud speed 115200 bps. It also contains two USB ports. These ports have 2.0 Hi-Speed interfaces with the data rate of 480 Mb/s. The maximum current flow rate from the host port is 1 A. The cDAQ 9133 also has a mini display port. This port has the resolution 2560 × 1600 with a frequency of 60 Hz. This model has an SD slot and supports SD and SDHC standards.
The NI cDAQ‑9133 has 127 sample rate per slot of analog inputs. The C series module determines the sample rate. The input channels have the timing precision of 50 ppm of the sampling rate. The device supports 16 on-board regenerated analog outputs. The maximum regeneration update rate is about 1.6 MS/s. It has similar timing precision and resolution as the analog inputs.
| Model | cDAQ-9133 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 783686-01, 783687-01 |
| Type | CompactDAQ Controller |
| Slots | 8 |
| Hard Drive Memory Size | 16 GB |
| Processor Core | 1.33 GHz Dual Core Intel Atom |
| Dimensions | 12.95 x 3.47 x 4.67 in. |
| Weight | 5 lb., 8.2 oz. |
| Warranty | 2-3 Year Warranty |
| cDAQ-9133 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for cDAQ-9133:
National Instruments cDAQ-9133 Frequently Asked Questions
Question: Why does the NI cDAQ-9133 Controller have two part numbers?
Answer: The NI cDAQ-9133 Controller has two operating system choices. Part number 783686-01 has Windows Embedded Standard 7 OS, while part number 783687-01 has NI Linux Real Time OS.
Question: Is there any way to connect the cDAQ 9133 with my computer HDD? Or is there another way to increase disk space?
Answer: For the cDAQ 9133, you can utilize a USB device as a hard disk drive.
Question: Can the cDAQ-9133 work with the Real-Time CompactRIO option?
Answer: The cDAQ-9133 is not a CompactRIO system and therefore will not work with Real-Time CompactRIO.
Question: Which SD cards are recommended for use with the NI cDAQ-9133?
Answer: The NI cDAQ-9133 works with SD and SDHC cards up to 32 GB.
Question: I’ve installed LabVIEW and there is now no room on my NI cDAQ 9133. How do I free up memory?
Answer: Make sure you’re using the Run-Time Engine version of the software components and executables if you’re only using the development environment for LabVIEW.
