National Instruments cDAQ-9173 CompactDAQ Chassis
The National Instruments cDAQ-9173 (part number: 789115-01) is a CompactDAQ Chassis that features plug-and-play USB capabilities designed for portable sensor measurement devices. This compact chassis is fully capable of managing the transfer of data, timing, and synchronization between various C Series I/O modules and an external host. The amount of analog input channels supported by the chassis, as well as the maximum sample rate of those channels, is determined by the specific C Series modules that are used. The cDAQ-9173 supports 16 (onboard regeneration) analog output channels, with a maximum update rate of 1.6 MS/s for multiple channels. Jackscrews with a torque of 3.6 lb · in. (0.41 N · m). are included with locking USB cables in order to secure the USB connectors.
Equipped with four general-purpose timers and counters that have 32 bits of resolution, the CompactDAQ Chassis is able to perform output applications that include equivalent time sampling, pulse / pulse train (with dynamic updates), and frequency division. The output frequency ranges from 0 MHz to 20 MHz, while the internal base clocks operate at 80 MHz, 20 MHz, and 100 kHz.
In terms of power requirements, the input voltage for the cDAQ-9173 Chassis ranges from 9 V to 30 V, with a required input power that is 15 W at maximum. The bus interface of the device is specified as a USB 2.0 Hi-Speed type, and it features 7 high-performance data streams. The chassis weighs in at 21.27 oz (603 g) and the physical dimensions measure 6.366 in. × 3.528 in. × 2.350 in. (161.70 mm × 89.61 mm × 59.70 mm) when it is not loaded. The temperature ranges for operation and storage are -20°C to 55°C and -40°C to 85°C, respectively, according to the official environmental specifications.
| Model Name | cDAQ-9173 |
|---|---|
| Part Number | 789115-01 |
| Part Type | CompactDAQ Chassis |
| Connector Type | USB C Connector Type |
| # Slots | 4 Slots |
| LEDs | Power, Status, and Active |
| Analog Input Timing Accuracy | 50 ppm of Sample Rate |
| # Counter/Timers | 4 |
| Counter/Timer Resolution | 32 Bits |
| Conformal Coated? | No |
| Onboard Trigger? | No |
| Synchronization? | Not Enabled |
| Operating Temp Range | -20 °C to 55 °C |
| Storage Temp Range | -40 °C to 85 °C |
| Dimensions | 6.366 in. × 3.528 in. × 2.350 in. (161.70 mm × 89.61 mm × 59.70 mm) Unloaded |
| Weight | 21.27 oz (603 g) Unloaded |
| Manufacturer | National Instruments |
