National Instruments cDAQ-9177 CompactDAQ Chassis
The cDAQ-9177 (part number: 789117-01) from National Instruments is a compact and portable CompactDAQ Chassis featuring plug-and-play USB capabilities perfect for sensor and electrical measurement applications. This durable chassis offers USB Type-C connectivity, and it can be used with a wide variety of C Series I/O modules to generate a mix of digital and analog I/O. The USB connectors are secured with jackscrews that are provided on locking USB cables, and the torque is 3.6 lb · in. (0.41 N · m).
The number of analog input channels that are supported by the cDAQ-9177 depend on the C Series modules that are used. A timing resolution of 12.5 ns is supported by the chassis, and the analog input has a FIFO size of 127 samples per slot. The device has a maximum update rate of 1.6 MS/s and offers 16 onboard regeneration channels for analog output. The analog output's timing accuracy is 50 ppm of the sample rate, and its timing resolution is also 12.5 ns. The cDAQ-9177 is also equipped with 4 general-purpose counter/timers that have 32 bits of resolution. These counter/timers have 0 MHz to 20 MHz of output frequency, and a dedicated 127-sample FIFO.
When it comes to power requirements, the CompactDAQ Chassis has an input voltage range of 9 V to 30 V—with a required input power that is 15 W at maximum. The specification for the bus interface of the cDAQ-9177 is Hi-Speed USB 2.0, which enables the 7 high-performance data streams of digital input & output, counter/timer input & output, analog input, and NI-XNET.
When unloaded, the physical dimensions of the chassis measure 10.087 in. × 3.528 in. × 2.350 in. (256.20 mm × 89.61 mm × 59.70 mm) and it weighs 32.59 oz (924 g). The environmental specifications include an operating temperature range from -20 °C to 55 °C and a storage temperature range of -40 °C to 85 °C.
| Model Name | cDAQ-9177 |
|---|---|
| Part Number | 789117-01 |
| Part Type | CompactDAQ Chassis |
| Connector Type | USB C Connector Type |
| # Slots | 8 Slots |
| Analog Input FIFO Size | 127 Samples / Slot |
| Counters/Timers | 4 General Purpose |
| Input Voltage Range | 9 V to 30 V |
| Conformal Coated? | No |
| Onboard Trigger? | No |
| Synchronization? | Not Enabled |
| Analog Input Timing Resolution | 12.5 ns |
| Operating Temp Range | -20 °C to 55 °C |
| Storage Temp Range | -40 °C to 85 °C |
| Dimensions | 10.087 in. × 3.528 in. × 2.350 in. (256.20 mm × 89.61 mm × 59.70 mm) Unloaded |
| Weight | 32.59 oz (924 g) Unloaded |
| Manufacturer | National Instruments |
