National Instruments cRIO-9043 CompactRIO Controller
The cRIO-9043 (Part numbers: 785620-01 and 785620-02) is a tough, elite, adaptable implanted Controller that offers Intel Atom double center preparing, NI-DAQmx bolster, and a SD card space for information logging, inserted checking, and control. This model incorporates a Kintex-7 160T FPGA with a LabVIEW FPGA Module bolster for cutting edge control and coprocessing. The Controller gives exact, synchronized planning and deterministic correspondences with Time Sensitive Networking (TSN), which is perfect for exceedingly circulated estimations. The cRIO 9043 Controller offers a few network ports, including Gigabit Ethernet, USB 3.1, USB 2.0, RS232, and RS485 ports. The USB 3.1 ports can be used to include a neighborhood human machine interface and program, convey, and troubleshoot programming, which improves application advancement
The FlexRIO product offering joins adaptable I/O and client programmable FPGAs into superior, reconfigurable instruments for clients with the LabVIEW FPGA Module. Moreover, the NI cRIO-9043 includes a mezzanine engineering that fits both the I/O module and the FPGA backend inside a solitary, coordinated 3U PXI module.
The user can utilize all of the items that are part of the 7 arrangement with a similar 28 nm HPL silicon process. In that case, Xilinx can focus significantly more on engineering development. For the 7 arrangement, Xilinx shows a full line of FPGAs. Xilinx has an amazing failure cost family called Artix-7 completely programmable FPGAs and a mid-run family called completely programmable Kintex-7 FPGAs, notwithstanding offering the renowned group of completely programmable FPGAs of a high Virtex-7 level.
| Model | cRIO-9043 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 785620-01, 785620-02 |
| Type | CompactRIO Controller |
| Slots | 4 |
| CPU Frequency | 1.30 GHz |
| Storage | 8 GB |
| Dimensions | 8.64 x 3.47 x 4.77 in. |
| Weight | 3 lbs., 15 oz. |
| Warranty | 2-3 Year Warranty |
| cRIO-9043 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for cRIO-9043:
National Instruments cRIO-9043 Frequently Asked Questions
Question: What is the difference between the two part numbers for the NI cRIO 9043?
Answer: Part number 785620-01 for the NI cRIO 9043 is not conformal coated and part number 785620-02 has added protection with conformal coating.
Question: What is the CPU frequency of the cRIO-9043?
Answer: The CPU frequency of the cRIO-9043 is 1.3 GHz (base), 1.8 GHz (burst).
Question: What is the flow control of the serial ports on the NI cRIO-9043?
Answer: The flow control of the RS-485 port is XON/XOFF, for the RS-232 Port flow control RTS/CTS, XON/XOFF, DTR/DSR when using the NI cRIO-9043.
Question: What SD cards are supported with the cRIO 9043?
Answer: The cRIO 9043 supports any SD cards that meet SD and SDHC standards.
cRIO-9043 PDF Manuals
CRIO-9043-LETTER-OF-VOLATILITY.PDF
CRIO-9043-SAFETY-ENVIRONMENTAL-AND-REGULATORY-INFORMATION.PDF
Driver Downloads for cRIO-9043
