National Instruments cRIO-9048 CompactRIO Controller
The cRIO-9048 (Part Numbers: 785619-01, 785619-02, and 785619-03) CompactRIO Controller comes with an Analog Input work that starts a change. The user should wait for the result, then restore the double portrayal of the voltage as a marked whole number. The measure of the information sort of the outcome differs by execution target. Ordinarily the user makes the FPGA VI to utilize the paired portrayal for tasks inside the FPGA VI. The user can additionally pass the twofold portrayal back to the host VI and change over the parallel portrayal back to a voltage. The difference between the cRIO-9048 part numbers is that part number 785619-02 is conformal coated, while part number 785619-03 is not. Part number 785619-01 is the version of the cRIO-9048 with extended temperature. The device is equipped with 8 slots, has a CPU frequency of 1.30 GHz, and a storage of up to 8 GB.
The user can utilize the Digital Input and Digital Port Input capacities to analyze the condition of an advanced terminal or computerized port. The condition of the computerized terminal is normally dictated by an outer signal, such as the yield produced by an outside gadget. Utilize the Digital Output and Digital Port Output capacities to set the condition of a computerized terminal or port. The user can utilize the Digital Input capacities to check the condition of a similar terminal to which the Digital Output work composes. The device is run using the NI-RIO driver software which is compatible with software packages like LabVIEW and C/C++.
Each VI or capacity the user puts in a FPGA VI sets aside a specific measure of opportunity to execute. The user can enable tasks to happen at the rate controlled by the dataflow without extra programming. If the user needs to control or measure the execution timing, utilize the Time and Dialog VIs. The user can likewise utilize the Time and Dialog VIs to make custom I/O, such as counters and triggers.
The NI device weighs 15 oz, and measures 12.94 x 3.47 x 4.77 in. in physical dimensions. It has a recommended operating temperature range of -40 °C to 70 °C, and a storage temperature range of -40 °C to 85 °C.
| Model | cRIO-9048 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 785619-01, 785619-02, 785619-03 |
| Type | CompactRIO Controller |
| Slots | 8 |
| CPU Frequency | 1.30 GHz |
| Storage | 8 GB |
| Dimensions | 12.94 x 3.47 x 4.77 |
| Weight | 4 lbs., 15 oz. |
| Warranty | Three Year Warranty |
| cRIO-9048 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for cRIO-9048:
National Instruments cRIO-9048 Frequently Asked Questions
Question: Is the cRIO-9048 able to be mounted directly on a flat surface?
Answer: Yes, the cRIO-9048 is designed to be mounted on a flat surface.
Question: What can I do to get the cRIO 9048 to work with the NI-9751 module?
Answer: In order to get the cRIO 9048 to work with the NI-9751, you need an additional patch update.
Question: Why am I getting error 307735 when I try to add a DAQ card to my NI cRIO-9048?
Answer: The NI cRIO-9048 with NI-DAQmx is only compatible with Veristand as a normal CompactRIO target.
Question: Can I connect a Display Port Monitor to the cRIO-9048?
Answer: Yes, a Display Port Monitor can be connected to the cRIO-9048 by using a Coms USB 3.1 Type C to Mini DP conversion cable. A USB C to HDMI or USB C to DVI cable can also be used, if your monitor has the ports.
cRIO-9048 PDF Manuals
CRIO-9048-LETTER-OF-VOLATILITY.PDF
CRIO-9048-SAFETY-ENVIRONMENTAL-AND-REGULATORY-INFORMATION.PDF
CRIO-9048-TPM-LETTER-OF-VOLATILITY.PDF
CRIO-9048-TPM-LETTER-OF-VOLATILITY_V1.PDF
CRIO-9048-TPM-LETTER-OF-VOLATILITY_V2.PDF
