National Instruments cRIO-9055 CompactRIO Controller
Featured with 2 Gigabit Ethernet ports and a MicroSD card slot, the NI cRIO-9055 (Part Number: 787043-01) is a CompactRIO Controller from National Instruments. This CompactRIO Controller comes with an extended temperature range and has 4 slots. Thus, the NI cRIO-9055 can host as many as four identical or different C Series modules simultaneously. This CompactRIO Controller comes equipped with a powerful, dual-core Intel Atom microprocessor that can operate at a maximum frequency of 1.33 GHz. Moreover, the onboard hardware resources include 2 gigabytes of RAM (random access memory) and 4 gigabytes of storage. You can always increase the storage capability of the cRIO-9055 by using a compatible MicroSD card.
This CompactRIO Controller supports communication over Ethernet and can auto-negotiate to adjust itself according to the configuration of your network. The two Ethernet ports support 1000Base-T, 100Base-TX, and 10Base-T network interfaces to communicate at 1000 Mb/s, 100 Mb/s, or 10 Mb/s respectively. The NI cRIO-9055 CompactRIO Controller can be powered through a 9 to 30 VDC power supply and consumes 30 watts of power while in operation and 3.4 watts in standby mode. However, National Instruments recommends the use of a 24 VDC, 60 W power supply with this CompactRIO Controller.
The reconfigurable FPGA incorporated in the National Instruments cRIO-9055 CompactRIO Controller is a Xilinx Artix-7 A100T FPGA, which comes with 126,800 flip-flops and 63,400 6-input LUTs. For nonvolatile storage, the NI cRIO-9055 has an integrated SSD (solid-state drive). This CompactRIO Controller features an internal frequency generator that can be lined up to any module PFI or controller PFI terminal.
| Model | cRIO-9055 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 787043-01 |
| Type | CompactRIO Controller |
| Slot Count | 4 |
| Processor Core | 1.33 GHz Dual Core Intel Atom |
| FPGA | Artix-7 100T |
| Maximum Power Consumption | 30 W |
| Dimensions | 8.72 in. × 3.25 in. × 3.53 in. |
| Weight | 2 lbs, 9 oz. |
| Warranty | 2-3 Year Warranty |
| cRIO-9055 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
