cRIO-9068 National Instruments CompactRIO Controller | Apex Waves | Image

❮ ❯

Actual item may vary if no part number is provided on quote request.

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Anonymous Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

Name*

Email Address*

Model Name

Part Number

Qty

+Add more parts

Additional Info - Calibration, Expedited Shipping or Other Notes

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to: 1-919-809-5227

Carol Zimme**** Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

National Instruments cRIO-9068 CompactRIO Controller

The National Instruments cRIO-9068 (Part Numbers: 782663-01 and 782663-02) is an Embedded, RT Controller designed for C Series Modules. This controller comes with a dual-core 667 MHz ARM Cortex-A9 processor, 512 MB DRAM, reconfigurable Zynq-7020 FPGA, 1 GB internal storage, and 8 slots. The NI cRIO-9068 is a combination of an embedded chassis and a real-time controller for CompactRIO.

This model comes with two RS-232 Serial Ports, one RS-485 Serial Port, two Ethernet Ports, as well as a Universal Serial Bus (USB) host port. Unlike its predecessor, the power connector of the cRIO-9068 has terminals for two power inputs, which allows the user to utilize redundant power supplies in a primary and secondary configuration. In its standard configuration, the NI cRIO-9068 operates from the primary power source (V1 input) and switches over to the secondary power source (V2) automatically when needed. The device has a 10/100/1,000 Ethernet network interface which is compatible with IEEE 802.3, and has communication rates of 10 Mbps, 100 Mbps, 1,000 Mbps auto-negotiated.

For the safety of the controller and associated power supplies, the cRIO-9068 Controller comes with reverse-voltage protection. Different power accessories are available on the market for this module, including: NI PS-15 (Part Number: 781093-01) and NI PS-10 (Part Number: 782698-01) power supplies. Moreover, the user can also acquire NI 9979 (Part Number: 196939-01), which is a strain relief specifically designed for the 4-position power connector incorporated in the NI cRIO-9068.

The NI cRIO-9068 operates using the NI-Industrial Communications for EtherCAT driver software. A choice Application Development Environment (ADE) such as LabVIEW is also required. The software can be configured using the Measurement & Automation Explorer (MAX) tool. The device has 16 DMA channels with 32 logical interrupts. Physically, the controller weighs 41.1 oz.

The universal serial bus host port provided in this model can be used for connecting various USB devices, including keyboards, a mouse, cameras, etc. The user can also utilize a USB-to-IDE adapter for attaching IDE storage devices with this controller. In most cases, USB mass storage devices are used to transfer data to or from the controller.

Model	cRIO-9068
Manufacturer	National Instruments
Part Numbers	782663-01, 782663-02
Type	CompactRIO Controller
Slots	8
Ethernet Ports	2
Processor Core	667 MHz Dual-Core ARM Cortex A9
DRAM	512 MB DDR3
Storage	1 GB NAND Flash
FPGA	Zynq-7000 (Z-7020)
DMA Channels	16
Logical Interrupts	32
Power Input Range	9 V to 30 V
GigE Vision Support?	No
Programming Method	LabVIEW FPGA
Extended Temperature?	Yes
Operating Temperature Range	-40 °C to 70 °C
Weight	41.1 oz (1,164 g)
cRIO-9068 Manual	User Manual and Specifications Available for Download
Price	Request a Quote for Information on Pricing

Associated part numbers for cRIO-9068:

National Instruments cRIO-9068 Frequently Asked Questions

Question: Does NI Veristand run on the NI cRIO-9068 Controller?

Answer: Unfortunately, Veristand Validation and Test software is not supported on the Controller.

Question: Can you deploy a second cRIO-9068 with similar configuration to another device?

Answer: Yes, you can replicate the cRIO controller using the replication and deployment utility.

Question: What does it mean when the status LED of the NI cRIO-9068 blinks twice every few seconds?

Answer: The LED blinking twice means there is a software error. Hit the reset button for 10 seconds, then format and reinstall the NI cRIO-9068 with the latest driver version.
