National Instruments sbRIO-9637 CompactRIO Single-Board Controller
The sbRIO-9637 (Part Numbers: 783818-02 and 783818-01) is a CompactRIO Single-Board Controller. The sbRIO-9637 is developed by National Instruments. The NI sbRIO-9637 is a member of the family of CompactRIO original equipment manufacturer (OEM) devices. The NI sbRIO-9637 requires the NI CompactRIO Device Drivers software August 2015 or later. This Controller additionally requires several types of LabVIEW software. The sbRIO-9637 operates with full functionality with the NI Linux 32-bit Real-Time operating system.
The NI sbRIO-9637 is built with a Xilinx Zynq-7000 FPGA. The sbRIO-9637 is fabricated with a dual-core processor. The architecture of the sbRIO-9637 is derived from the ARM Cortex A9. This CompactRIO Single-Board Controller is available with a volatile memory of 512 MB. The sbRIO-9637 is also equipped with 512 MB of non-volatile memory.
The National Instruments sbRIO-9637 has a RIO Mezzanine Card (RMC) connector. The NI sbRIO-9637 is additionally featured with multiple types of ports, such as USB host ports, a CAN port, a DIO port, an MIO port, an SD connector, and an Ethernet port. The NI sbRIO-9637 is prepared with SDHC ports, an RS-485 serial port, and two RS-232 serial ports.
The sbRIO-9637 comes with 16 analog input channels and 4 analog output channels with 16-bit ADC resolution. The sbRIO-9637 contains 28 digital input/output lines with 3.3 V. The sbRIO-9637 requires an external 9 VDC to 30 VDC power supply.
sbRIO-9637 Obsolete Status has been announced by National Instruments, but the controller will still be available for purchase and repairs by Apex Waves.
| Model | sbRIO-9637 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 783818-02 and 783818-01 |
| Type | CompactRIO Single-Board Controller |
| FPGA | Xilinx Zynq-7000 |
| Architecture | ARM Cortex-A9 |
| Cores | 2 |
| Power Consumption | 26 W Maximum |
| Weight | 4.540 oz. |
| Warranty | 2-3 Year Warranty |
| sbRIO-9637 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for sbRIO-9637:
National Instruments sbRIO-9637 Frequently Asked Questions
Question: What is the speed of the sbRIO-9637's processor?
Answer: The processor speed is 667 MHz.
Question: What operating system is supported by the controller?
Answer: The sbRIO-9637 supports the 32-Bit version of the NI Linux Real-Time OS.
Question: What is the maximum cabling distance of the sbRIO-9637?
Answer: The cRIO Controller has a max cabling distance of 100 m/segment.
Question: What is the power consumption?
Answer: The sbRIO-9637 has a maximum power consumption of 26 W.
