National Instruments sbRIO-9697 C Series RIO Mezzanine Card
The NI sbRIO-9697 (Part Number: 783883-01) is a C Series RIO Mezzanine Card with two slots that is intended to communicate with the NI sbRIO-9607/9627 devices. Its main purpose is to enable the connecting of these sbRIO devices to up to two board-only C Series modules, hence increasing their variety and functionality in industrial automation applications. Twenty-four digital input/output (DIO) channels are available on this mezzanine card, giving users flexibility for a range of control and monitoring activities. Every channel functions at 3.3 V and has a maximum tested current capacity of ±3 mA.
In order to provide compatibility with various signal sources, the input logic levels vary from 0 V to 0.8 V for low and 2.0 V to 5.25 V for high. For output, the card maintains a voltage range of 2.4 V to 3.465 V for high when sourcing 3 mA and 0.0 V to 0.4 V for low when sinking 3 mA. This ensures reliable signal transmission and compatibility with downstream devices. Installation and assembly are straightforward, with torque specifications provided for securing the card in place. The card itself is lightweight, weighing only 82.8 g (2.92 oz), minimizing additional load on the system. The sbRIO-9697 contains features for thermal validation, as thermal concerns are critical in industrial settings. The C Series modules that are exclusive to the board are to have their operating temperature measured 7.6 mm (0.3 in.) above the module surface in order to ensure safe and effective functioning within the designated temperature limits.
With a noncondensing operational humidity range of 10% to 90% and a storage temperature range of -40 to 85 degrees Celsius, the device satisfies international requirements for both storage and operating conditions. It can also be stored in noncondensing conditions with humidity levels between 5% and 95%. Furthermore, the maximum operating altitude of 5,000 meters guarantees compatibility with a broad variety of deployment circumstances.
| Model Name | sbRIO-9697 |
|---|---|
| Part Number(s) | 783883-01 |
| Manufacturer | National Instruments |
| Product Type | Two-slot C Series RIO Mezzanine Card |
| Number of DIO Channels | 24 |
| Maximum Tested Current per Channel | ±3 mA |
| Input Low Voltage (VIL) | 0 V min; 0.8 V max |
| Input High Voltage (VIH) | 2.0 V min; 5.25 V max |
| Output High Voltage (VOH) | 2.4 V min; 3.465 V max (when sourcing 3 mA) |
| Output Low Voltage (VOL) | 0.0 V min; 0.4 V max (when sinking 3 mA) |
| Torque for Screws | 0.45 N · m (4.0 lb · in) |
| Operating Temperature Range | -40 °C to 85 °C |
| Operating Humidity Range | 10% RH to 90% RH, noncondensing |
| Maximum Altitude | 5,000 m |
Associated part numbers for sbRIO-9697:
National Instruments sbRIO-9697 Frequently Asked Questions
Question: What devices is the card compatible with?
Answer: The sbRIO-9697 is compatible with NI sbRIO-9607/9627 devices.
Question: What is the function of the sbRIO-9697?
Answer: The NI sbRIO-9697 is an accessory you can use to connect up to two board-only C Series modules to the NI sbRIO-9607/9627.
Question: How many channels does the sbRIO-9697 have?
Answer: The RIO Mezzanine Card has 24 digital input/output (DIO) channels.
