NI PCIe-6341, 16 Analog Inputs, 24 Digital I/O, Multifunction Data Acquisition Device
Rated 4.86/5 | 21 ratings
Actual item may vary if no part number is provided on quote request.
✔ 2 Year Warranty Included
✔ Free Ground Shipping
✔ NIST Calibration Available
National Instruments PCIe-6341 Multifunction DAQ Device
National Instrument's PCIe-6341 (Part Number: 781046-01, 194986E-03L) is a multifunction data acquisition (DAQ) device that is intended to provide high-performance functionality for a range of industrial automation applications. To provide dependable performance, it makes use of the high-throughput PCI Express bus as well as multicore-optimized application and driver software.
With 16 single-ended or 8 differential analog input channels with 16-bit resolution and a maximum sample rate of 500 kSamples/s per channel, this device provides a variety of analog and digital I/O possibilities. The analogue input portion has a narrow signal bandwidth of 1.2 MHz, high input impedance, and overvoltage protection. For analog output, the PCIe-6341 provides 2 channels with 16-bit resolution and a maximum update rate of 900 kSamples/s for single-channel operation.
Having a settling time of 6 µs and a slew rate of 15 V/µs, it can generate waveforms in both periodic and non-periodic modes. The device has 24 channels available for digital input/output (I/O); 8 of those channels are for static digital I/O, and the remaining 16 are for programmable function interface (PFI). It has input voltage protection, pull-down resistors, and programmable direction control. The PCIe-6341 also has four 32-bit counters/timers that can measure edge counting, pulse width, and quadrature encoding, among other things.
The enhanced timing functionality and retriggerable measurement tasks offered by NI-STC3 timing and synchronization technology are features of these counters. Applications including data logging, test automation, and control systems are good fits for this device. Custom measurement systems and control algorithms are simple to design using NI-DAQmx driver support and user-friendly graphical programming software. Applications demanding deterministic operation benefit greatly from the low-latency PCI Express bus, which guarantees effective single-point I/O performance.
Model | PCIe-6341 |
---|---|
Manufacturer | National Instruments |
Part Number | 781046-01, 194986E-03L |
Series | X Series |
Type | Multifunction I/O Device |
Analog Input Channels | 16 (16-Bit, 500 kS/s) or 08 differential |
Analog Output Channels | 2 (16-Bit, 900 kS/s) |
Digital Inputs | 16 |
Digital Outputs | 8 |
Timing I/O | 4 Counter/Timer I/O (32 bits, 100 MHz) |
Frequency Generator Channels | 1 |
Phase-Locked Loop (PLL) | 1 |
I/O Connector | 1 68-pin VHDCI |
Power Requirements | +3.3 V, +12 V -- 1A, 1.4 W, 8.6 W |
Dimensions | 3.9 in. × 6.6 in. |
Weight | 0.23 lb. |
Driver Software | NI-DAQmx 9.0 |
Warranty | Three Year Warranty |
PCIe-6341 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for PCIe-6341:
National Instruments PCIe-6341 Frequently Asked Questions
Question: Can I use a low-profile bracket with my PCIe-6341?
Answer: No, this X Series Device does not fit a low-profile bracket.
Question: Which driver is used with the NI PCIe-6341?
Answer: The Multifunction I/O Device is compatible with the NI-DAQmx driver.
Question: My PCIe-6341 is running slow when I do an “inputSingleScan” command. What can I do?
Answer: Check your driver and ensure that it’s the latest version. If you’re still having problems, reach out to us at support@apexwaves.com.
DAQ-GETTING-STARTED-GUIDE-FOR-PCI-PCI-EXPRESS.PDF
DAQ-GETTING-STARTED-READ-ME-FIRST-NI-DAQMX-AND-DAQ-DEVICE-INSTALLATION-GUIDE.PDF
NI-62XX-63XX-PINOUT-LABELS-FOR-THE-SCB-68-NOTE-TO-USERS.PDF
NI-62XX-63XX-PINOUT-LABELS-FOR-THE-SCB-68A-NOTE-TO-USERS.PDF
NI-PCIE-6320-21-23-41-43-LETTER-OF-VOLATILITY.PDF
