National Instruments PCI-4452 Dynamic Signal Acquisition Device
The National Instruments PCI-4452 (Part number: 778317-01) comes with a Measure function, which is an information acquisition and instrument control that is included for Microsoft Excel. With Measure, the user can procure information straightforwardly from module DAQ boards, GPIB instruments, or serial (RS-232) gadgets. The measure function has simple-to-utilize discourse boxes for designing estimations. The user’s information is set specifically into Excel worksheet cells, from which the user can play out their examination and report generation utilizing the full power and adaptability of Excel. National Instruments also offers links of various lengths to interface the advanced I/O signs to the NI PCI 4452. To build up a particular link, keep in mind that the computerized I/O mating connector is a 50-position connector.
The NI PCI-4452 utilizes differential (DIFF) inputs. The user can arrange the contribution as a referenced single-ended (SE) channel utilizing the BNC-2140 DSA accessory. In DIFF mode, one line associates with the positive contribution of the channel and alternately interfaces with the negative contribution of a similar channel. The user can associate the differential contribution to SE or DIFF signals, either floating or ground-referenced. In any case, establishing the negative contribution from floating sources may enhance the estimation quality by expelling the regular mode noise. This model comes with a product programmable switch that decides if a capacitor is set in the signal way. If the switch is set for DC, the capacitor is circumventing and any DC counterbalance exhibit in the source signal is passed to the ADC.
PCI-4452 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.
| Model | PCI-4452 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 778317-01 |
| Type | Dynamic Signal Acquisition Device |
| Channels | 4 |
| Resolution | 16 bits |
| Sample Rate | 5 kS/s to 204.8 kS/s |
| Dimensions | 4.19 x 12.28 x 0.73 in. |
| Analog I/O Connector | 68-pin VHDCI female |
| Warranty | 2-3 Year Warranty |
| PCI-4452 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCI-4452:
National Instruments PCI-4452 Frequently Asked Questions
Question: Which trigger modes are available on the NI PCI 4452?
Answer: The NI PCI 4452 has pretrigger mode, delya trigger mode, and posttrigger mode.
Question: What is the input configuration of the analog input channels on the NI PCI-4452?
Answer: The input configuration of the analog input channels on the NI PCI-4452 is simultaneously sampled balanced differential.
Question: What is the power-on state of the digital I/O channels on the PCI 4452?
Answer: The power-on state of the digital I/O channels on the PCI 4452 is input (high-impedance).
Question: How often should the PCI-4452 be calibrated?
Answer: The PCI-4452 should be calibrated every year.
