National Instruments PXI-4472B PXI Sound and Vibration Module
The PXI-4472B (Part number: 778279-02) is a Sound and Vibration Module manufactured by National Instruments with eight simultaneously sampled analog input channels, 24 bits of resolution, AC/DC coupling, a maximum sampling rate of 102.4 kS/s, and 0.5 Hz cutoff frequency. This module utilizes a conversion technique called delta-sigma modulation, which means if the desired data rate is 51.2 kS/s, then every ADC will sample the input signal at 6.5536 MS/s. Several more steps follow, but the outcome is a wide dynamic range.
The analog trigger circuitry on the PXI-4472B can be constructed to keep track of any input channel which the user has obtained information from. If the user designates an input channel as the trigger channel, then it will not affect the input channel’s procurement capabilities. Additionally, the user can arrange their Sound and Vibration Module to begin gathering samples after the input signal reaches a certain point.
A few analog triggering modes are available on the National Instruments PXI-4472B, including: window triggering, analog edge, and analog edge with hysteresis. Firstly, window triggering happens when an analog signal arrives or leaves a window determined by two levels. The user can designate the levels by choosing a value for the top and bottom window limitations. For analog edge triggering, the module can be arranged to discover a specific Level and slopes for signals. On the other hand, analog edge triggering with hysteresis allows the user to add a window over or under the trigger level. This trigger type is most commonly implemented to decrease inaccurate triggering caused by noise or jitter in the signal. The device has a power requirement of 400 mA maximum at +3.3 VDC, 2000 mA at +5 VDC, 120 mA max at both +12 and -12 VDC. The NI device weighs 8.5 oz, and measures 6.3 x 3.9 in. in physical dimensions. It has a recommended operating temperature range of 0 to 55 °C, and a storage temperature range of –20 to 70 °C.
The PXI-4472B has reached Obsolete Status from National Instruments (NI), but the Sound and Vibration Module will still be available for both purchase and repairs in perpetuity with Apex Waves.
| Model | PXI-4472B |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 778279-02 |
| Series | DSA Devices |
| Part Type | PXI Sound and Vibration Module |
| Analog Input Channels | 8, Simultaneously Sampled |
| High-Pass Filter Cutoff Frequency | 0.5 Hz |
| Maximum Sample Rate | 102.4 kS/s |
| ADC Type | Delta-Sigma |
| Analog I/O Connectors | SMB Male Connector |
| Operating Temp Range | 0° to 55 °C |
| Storage Temp Range | –20° to 70 °C |
| Dimensions | 6.3 × 3.9 in. (16.0 × 9.9 cm) |
| Weight | 8.5 oz (241 g) |
| Warranty | Three Year Warranty |
| PXI-4472B Manual | User Manual and Maintenance Manual Available for Download |
| Price | Request a Quote for More Information |
