Q: What is the maximum sample rate of the PXI-4495?

The maximum sample rate of the PXI-4495 is 204.8 kS/s.

Q: What is the recommended software for use with the NI PXI-4495?

The recommended software for the NI PXI-4495 is LabVIEW, LabVIEW Real-Time, and Sound and Vibration Measurement Suite.

Q: What are the gain settings on the PXI-4495?

The gain settings on the PXI-4495 are 0 and 20 dB.

Q: Why does the PXI-4495 Sound and Vibration Module have two part numbers?

The PXI-4495 Sound and Vibration Module has two part numbers because the 780059-01 is the regular module and the 780060-01 comes with the Sound and Vibration Measurement Suite software.

PXI-4495, 16-Channel, PXI Sound and Vibration DSA Device

Rated 4.6/5 | 20 ratings

PXI-4495 National Instruments PXI Sound and Vibration Module | Apex Waves | Image

❮ ❯

Actual item may vary if no part number is provided on quote request.

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Anonymous Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

Name*

Email Address*

Model Name

Part Number

Qty

+Add more parts

Additional Info - Calibration, Expedited Shipping or Other Notes

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to: 1-919-809-5227

Carol Zimme**** Verified Buyer

" Very responsive and helpful, competitive pricing. Good source! "

July 2025

Andrew Gar**** Verified Buyer

" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "

March 2025

Said Sai**** Verified Buyer

" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "

January 2025

Bob C**** Verified Buyer

" Jason was able to get our emergency situation taken care of quickly and professionally. "

May 2025

Gregg Flecki**** Verified Buyer

" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "

January 2025

National Instruments PXI-4495 PXI Sound and Vibration Module

The National Instruments PXI-4495 PXI Sound and Vibration Module is intended for high-channel-count sound and vibration applications. There are two different part numbers: 780059-01 for the standard module and 780060-01 which includes the Sound and Vibration Measurement Suite Software. With 24-bit simple sources of input and IEPE constant current signal module, the PXI-4495 is perfect for making accuracy estimations with microphones, accelerometers, and different transducers that have huge dynamic reaches. The PXI-4495 delivers synchronous sampling on all channels. Moreover, the PXI-4495 incorporates built-in antialiasing filters that consequently change in accordance with the examining rate and programming selectable information gains to 20 dB.

The NI-DAQmx driver and estimation measurement services software provides simple-to-utilize configuration and programming interfaces with highlights, such as the DAQ Assistant to help diminish development time. The user can browse the data in the Resources tab to learn more about driver software or download a driver. The NI M Series gadgets are not compatible with the Traditional NI-DAQ (Legacy) driver.

Each input signal is simultaneously buffered, amplified, analog filtered, and inspected by a 24-bit delta-sigma analog to-digital converter (ADC) that performs digital filtering with a cutoff recurrence that consequently adjusts to a software sampling rate. The high resolution gives the vital precision to make the NI PXI-4495 module appropriate for sound and vibration examination applications. A programmable gain amplifier stage on the inputs offers gain selection from 0 to +30 dB in 10 dB steps. Moreover, the modules incorporate the ability to read and write to transducer electronic information sheet (TEDS) Class 1 smart sensors and also work with IEPE constant current on or off as selected in software.

Model	PXI-4495
Manufacturer	National Instruments
Part Numbers	780059-01 and 780060-01
Type	PXI Sound and Vibration Module
Analog Inputs	16
Resolution	24-bit
Dynamic Range	114 dB
Coupling	DC
Warranty	2-3 Year Warranty
PXI-4495 Manual	User Manual and Maintenance Manual Available for Download
Price	Contact a sales representative for a quote.

Associated part numbers for PXI-4495:

National Instruments PXI-4495 Frequently Asked Questions

Question: What is the maximum sample rate of the PXI-4495?

Answer: The maximum sample rate of the PXI-4495 is 204.8 kS/s.

Question: What is the recommended software for use with the NI PXI-4495?

Answer: The recommended software for the NI PXI-4495 is LabVIEW, LabVIEW Real-Time, and Sound and Vibration Measurement Suite.

Question: What are the gain settings on the PXI-4495?

Answer: The gain settings on the PXI-4495 are 0 and 20 dB.

Question: Why does the PXI-4495 Sound and Vibration Module have two part numbers?

Answer: The PXI-4495 Sound and Vibration Module has two part numbers because the 780059-01 is the regular module and the 780060-01 comes with the Sound and Vibration Measurement Suite software.
