National Instruments PCI-6070E Multifunction DAQ

The PCI-6070E or PCI-MIO-16E-1 is a Multifunction DAQ by National Instruments. The PCI-6070E is available under part number 777305-01. The PCI-6070E is one of the high-speed and accurate multiplexed DAQ devices. The prominent features of this device are flexibility and noise and jitter immunity. The PCI-6070E offers a low consumption of power and a self-calibration feature. Self-calibration is controlled through software. This model also has protection against temperature drift. The NI PCI-6070E device supports various OS and application software choices such as LabVIEW, LabWindows/CVI, or Measurement Studio. The PCI-607E offers more than 70 signal conditioning choices. This device supports an RTSI Trigger bus, which enables the PCI-6070E to synchronize multiple devices.

The PCI-6070E Multifunction DAQ has 32 analog input channels. These channels can be programmed to operate as 16 differential inputs. Each channel of this model is independent. The input channels have a voltage range of 10 Volts. The input channels of this device support dual polarity. These channels are selectable as both unipolar and bipolar. In bipolar mode, the voltage range is -5 V to +5 V. The ADC resolution of the input channels is 12 bits. The maximum sampling time of the device is 1.25 MS/sec. The DAQ device has 2 analog output channels with a 12-bit resolution and a sampling rate of 1 MS/s. It has 8 digital I/O channels (with 5 V/TTL compatibility) and 2 counter/timer I/O lines (with a resolution of 24 bits and a frequency of 20 MHz. The NI PCI-6070E includes a FIFO buffer. The memory of the FIFO buffer is 2,048 samples. The device is equipped with a 68-pin male 0.050 D-type I/O connector.

The PCI-6070E is ideal for a broad range of applications.  This device can log fast data without any interruptions. The device is also used in control applications. The NI PCI-6070E is compatible with high voltage signals and sensor measurements. This model supports integration with motion control and mission vision. This attribute makes it appropriate to design control systems.

The NI device weighs 4.1 oz, and measures 6.9 x 4.2 in. in physical dimensions. It has a recommended operating temperature range of 0 to 55 °C, and a storage temperature range of –20 to 70 °C.

ModelPCI-6070E
ManufacturerNational Instruments
Part Number777305-01
SeriesE Series
TypeMultifunction DAQ
Channels16 Analog Inputs (12-Bit, 1.25 MS/s) or 8 differential
2 Analog Outputs (12-Bit,1 MS/s)
8 Digital Inputs/Outputs (5 V/TTL Compatibility)
2 Counter/Timer I/O (24 bits, 20MHz )
I/O Connector68-pin Male 0.050 D-type
Power Requirements+5 VDC - 1.1 A
Dimensions6.9 × 4.2 in.
Weight4.1 oz.
Driver SoftwareNI-DAQ7
WarrantyThree Year Warranty
PCI-6070E ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PCI-6070E:

National Instruments PCI-6070E Frequently Asked Questions



Question: How much current does the PCI-6070E draw?



Answer: The PCI-6070E or PCI-MIO-16E-1 draws 1.1A at the PCI connector.



Question: Which type of I/O connector does the NI PCI-6070E have?



Answer: The NI PCI-6070E has a 68-pin male 0.050 D-type I/O connector.



Question: What is the maximum working voltage of the PCI-6070E?



Answer: The maximum working voltage of the PCI-6070E is ±11 V.



Question: How often should the NI PCI-6070E be calibrated?



Answer: The NI PCI-6070E should be calibrated once per year.
