FP-DO-AC240 National Instruments Discrete Output Module | Apex Waves | Image
FP-DO-AC240 National Instruments Discrete Output Module | Apex Waves | Image
FP-DO-AC240 New
FP-DO-AC240 Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

FP-DO-AC240 National Instruments Discrete Output Module | Apex Waves | Image
FP-DO-AC240 National Instruments Discrete Output Module | Apex Waves | Image
FP-DO-AC240 New
FP-DO-AC240 Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments FP-DO-AC240 FieldPoint Discrete Output Module

The FP-DO-AC240 is a Discrete Output Module for the FieldPoint series. The NI FP-DO-AC240 is created by National Instruments. This module can be ordered under part number 778071-12. The channels on this module are discrete AC output channels. Therefore, the FP-DO-AC240 is designed for those applications where discrete AC type signals are required.  This module is almost identical to that of the FP-DO-AC120 module. These modules differ only in their output voltage range. The FP-DO-AC240 output can be anywhere in the range of 24 – 280 VAC with a frequency between 25 – 70 Hz. The NI FP-DO-AC240 outputs are triac-style at zero-crossing.

This Discrete Output Module can easily be mounted on the suitable FP-TB series terminal block. The FP-TB series is a convenient way to install the FP-DO-AC240 and other I/O modules. The FP-TB Terminal Blocks offer both screw and spring terminals where field wiring connections can be made. The NI FP-DO-AC240 has isolated dual channels. Both channels can be used independently for either sourcing or sinking devices. These channels also have a fuse to keep the module safe in case of short circuit. Other protection schemes that are designed for the module include overvoltage protection up to 2300 Vrms transients.

The FP-DO-AC240 has LEDs for user convenience. These LEDs light up green when the respective channel is in the ON state. The NI FP-DO-AC240 is a plug-and-play module. This means there is no need of installation of any special driver software. The module is automatically detected and installed by the PC. The power required by this Discrete Output Module is 70 mW.

ModelFP-DO-AC240
ManufacturerNational Instruments
Part Number778071-12
TypeDiscrete Output Module
Output Channels2
Voltage Range24 to 280 VAC; 25 to 70 Hz
Maximum Leakage4 mA rms
Voltage Drop1.0 V at 0.5 A
Power Requirement70 mW
Warranty2-3 Year Warranty
FP-DO-AC240 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
