National Instruments FP-DO-DC200 Discrete Output Module

The FP-DO-DC200 is a FieldPoint Discrete Output Module. The FP-DO-DC200 is designed and manufactured by National Instruments. The part number of this dual-channel module is 778071-14. The output of the channels is discrete. The NI FP-DO-DC200 module features optical isolation. This Discrete Output Module can easily be mounted on a DIN rail. The FP-DO-DC200 is a plug-and-play module. HotPNP operation mode is a special feature of the module.

The NI FP-DO-DC200 Discrete Output Module features fused output channels, which means that each channel of the module is equipped with a separate fuse. The National Instruments FP-DO-DC200 module also offers transient overvoltage protection. This Discrete Output Module can absorb up to 2300 Vrms voltage transients and surges without being damaged. Other features of the module include green LEDs dedicated for each channel of the module. These LEDs indicate the ON/OFF state of the channel.

The NI FP-DO-DC200 is suitable for a variety of applications. This Discrete Output Module is particularly useful for those applications where isolation is a requirement. The isolated design of the module makes it compatible with both sinking and sourcing modules. The voltage range of the FP-DO-DC200 is 4- 200 VDC. Each channel of the Discrete Output Module has a current rating in a range of 0.3 – 0.75 A. The amount of current mainly depends upon the ambient temperature. The National Instruments FP-DO-DC200 module supports both AC and DC loads. This module can be used in different applications involving lamps, motors, and solenoid loads.

ModelFP-DO-DC200
ManufacturerNational Instruments
Part Number778071-14
TypeDiscrete Output Module
Output Channels2
Voltage Range4 to 200 VDC
Maximum Output Delay0.75 ms
Voltage Drop1.75 V at 1.0 A
Power Requirement70 mW
Warranty2-3 Year Warranty
FP-DO-DC200 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
