National Instruments NI-5752B Digitizer Adapter Module for FlexRIO
The National Instruments NI-5752B (Part Number: 784062-01) is a 32-Channel, 12-Bit Digitizer Adapter Module for FlexRIO. This model is designed for FlexRIO systems, and it can acquire samples at 50 MS/s. The NI-5752B is usually used with a PXI FPGA Module - a combination that works as a high-speed digitizer and is capable of sampling up to 32 channels. With this module, users can also utilize high-performance A/D converters to achieve streaming of analog data and real-time processing. The NI-5752B comes with an integrated sample clock with 25 MHz to 50 MHz frequency range.
This Digitizer Adapter Module for FlexRIO is an ideal choice for applications where high data streaming rates and in-line data processing are required. The NI-5752B offers 32 differential, simultaneously sampled channels (AI 0 to AI 32), through 2 VHDCI (dual stack) connectors in AC-coupled mode. This module comes with a 12-bit A/D converter, with a variable gain amplifier. With this module, users can acquire Digital Inputs through 2 channels at 2.0 V Minimum high-level input voltage and 0.8 V Maximum low-level input voltage.
The NI 5752B module offers 16 DO channels through a VHDCI connector and can generate outputs at 1 mA maximum output current, 10 ns minimum pulse width, and 1 MHz maximum toggle frequency. The National Instruments NI-5752B requires 5.3 W of total power from the host FPGA device. In total, this module has one SMB connector and three 68-pin VHDCI connectors mounted on the front panel.
| Model | NI-5752B |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 784062-01 |
| Type | Digitizer Adapter Module for FlexRIO |
| Voltage Input Channels | 32 |
| Maximum Sample Rate | 50 MS/s |
| Analog Input Resolution | 12 bits |
| Dimensions | 5.1 x 0.8 x 4.7 in. |
| Weight | 10 oz. |
| Warranty | 2-3 Year Warranty |
| NI-5752B Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for NI-5752B:
National Instruments NI-5752B Frequently Asked Questions
Question: What type of digital input and output connectors are on the NI-5752B?
Answer: There are VHDCI digital input and output connectors on the NI-5752B.
Question: What is the sample clock frequency range for the NI 5752B?
Answer: The NI 5752B has a sample clock frequency range of 25 MHz to 50 MHz.
Question: What type of FPGA is compatible with the NI-5752B?
Answer: The NI-5752B is compatible with Kintex-7 and Virtex-5 FPGAs.
Question: What is the total power requirement for the NI 5752B?
Answer: The total power requirement for the NI 5752B is 5.3 W.
