National Instruments NI-5753 Digitizer Adapter Module for FlexRIO
The National Instruments NI-5753 is a 16-Bit Digitizer Adapter Module, designed explicitly for FlexRIO based systems. This powerful module can sample 12 channels simultaneously at 120 MS/s in conjunction with a PXI FPGA Module for FlexRIO. This Digitizer Adapter Module is offered in an AC-coupled version (Part Number: 784429-01) and a DC-coupled version (Part Number: 784429-02). The AC-coupled build of the NI-5753 comes with 16 channels and 0.1 MHz to 250 MHz frequency range. However, the DC-coupled build has 12 channels and DC to 250 MHz frequency range. The National Instruments NI-5753 features a robust, AD9653 type analog-to-digital converter (ADC).
This module has a 120 MHz internal sample clock to provide access to the external sample clock and external reference clock. This module comes equipped with a dedicated, CLK in connector. As far as its AUX I/O characteristics are concerned, the NI 5753 offers 16 AC-coupled analog input channels and 12 directional channels (8 DIO and 4 PFI) through HDMI connectors. Both variations of this module are compatible with Kintex-7 and Virtex-5 FPGAs. In its AC-coupled build, the NI-5753 can operate over an analog input voltage range of -0.9 Vpp to 0.9 Vpp.
The AC-coupled CLIP provided with this model comes with a User Command Interface provision; thus, it can be used for sending raw I2C and SPI access to the module and to select different clock modes. The National Instruments NI-5753 offers a variety of clocking options. The clock source not only controls the sample rate, but other timing functions on the device as well.
| Model | NI-5753 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 784429-02, 784429-01 |
| Type | Digitizer Adapter Module for FlexRIO |
| Voltage Input Channels | 12 or 16 |
| Maximum Sample Rate | 120 MS/s |
| Analog Input Resolution | 16 bits |
| Dimensions | 4.6 x 0.8 x 4.0 in. |
| Weight | 11.2 oz. |
| Warranty | 2-3 Year Warranty |
| NI-5753 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for NI-5753:
National Instruments NI-5753 Frequently Asked Questions
Question: Why are there two part numbers for the NI-5753?
Answer: The NI-5753 has two part numbers with different specifications. Part number 784429-02 has 12 voltage input channels, DC analog input coupling, 117 MHz analog input bandwidth, and -0.45 to 0.45 V analog input voltage range. However, part number 784429-01 has 16 voltage input channels, AC analog input coupling, 176 MHz analog input bandwidth, and -0.9 to 0.9 Vpp analog input voltage range.
Question: What is the frequency range for the NI 5753?
Answer: The frequency range for the NI 5753 is DC to 250 MHz for part number 784429-02 and 0.1 MHz to 250 MHz for part number 784429-01.
Question: What type of front panel connectors does the NI-5753 module have?
Answer: The NI-5753 module has one ganged MCX connector, one SMB connector, and one HDMI connector on the front panel.
Question: What is the power draw for the NI 5753?
Answer: For the NI 5753, the power draw is 5.40 W for part number 784429-01 and 5.62 W for part number 784429-02.
