National Instruments PXIe-7911 PXI FlexRIO Coprocessor Module

The PXIe-7911 is a PXI FlexRIO Coprocessor Module. The manufacturer of the PXIe-7911 module is National Instruments. National Instruments has launched the NI PXIe-7911 module with the part number 785172-01. The PXIe-7911 module is a member of the FlexRIO products by National Instruments. The NI PXIe-7911 module contains an FPGA that can be activated by LabVIEW software. The Xilinx Vivado is also used for programming additional tasks in the FPGA controller.

The NI PXIe-7911 PXI FlexRIO Coprocessor Module is built with a KU035 FPGA. The FPGA in the PXIe-7911 module can be programmed with Xilinx Vivado to offer additional signal-processing tasks for PXI Express systems. The NI PXIe-7911 module is an x8 Gen 3 PXI module. The PXIe-7911 has peer-to-peer streaming capabilities. The NI PXIe-7911 is fabricated with a block RAM (BRAM) of 19 Mbit and 0 GB of dynamic ram (DRAM). National Instruments provides 1700 DSP slices within the PXIe-7911 FlexRIO Coprocessor Module. This module does not have auxiliary I/O.

The NI PXIe-7911 FlexRIO Coprocessor Module is built with 50780 FPGA slices. The PXIe-7911 supports PXI triggering, as well as PXI star triggering functions. The National Instruments PXIe-7911 module is manufactured with 60 DMA channels. The NI PXIe-7911 module can be paired with other PXI devices like PXI Vector Signal Transceivers for additional functionalities. The PXIe-7911 PXI FlexRIO Coprocessor Module works with moderate processing for signal-based applications. The NI PXIe-7911 module is compatible with chassis that can function with a power capacity of 58 W or more.

ModelPXIe-7911
ManufacturerNational Instruments
Part Number785172-01
TypePXI FlexRIO Coprocessor Module
FPGA TypeKintex UltraScale KU035
DRAM0 GB
BRAM19 Mbit
FPGA Slices50780
Dimensions7.4 in. × 5.1 in.
Weight6.7 oz.
Warranty2-3 Year Warranty
PXIe-7911 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
