National Instruments PXIe-7912 PXI FlexRIO Coprocessor Module

The PXIe-7912 is a PXI FlexRIO Coprocessor Module. National Instruments designs the PXIe-7912 module. The part number for the NI PXIe-7912 module is 785173-01. The PXIe-7912 module is associated with the FlexRIO Series of products from National Instruments. The NI PXIe-7912 module contains a Kintex UltraScale KU040 reconfigurable FPGA that can be programmed with LabVIEW software or Xilinx Vivado for additional signal-processing features in PXI Express systems. The NI PXIe-7912 module operates the FPGA with 1920 DSP slices. The PXIe-7912 module comes with 60600 FPGA slices.

The NI PXIe-7912 module comes with 4 HSS auxiliary input/outputs and 8 GPIO. The National Instruments PXIe-7912 PXI FlexRIO Coprocessor Module is developed with 4 GB of Dynamic RAM (DRAM) and 1064 MHz DRAM clock rate. The form factor of the PXIe-7912 module is PCI Express Gen-3 x8. Peer-to-peer data streaming is possible with the NI PXIe-7912 FlexRIO Coprocessor Module. The PXIe-7912 module is configured with 21 Mbit of BRAM.

The National Instruments PXIe-7912 PXI FlexRIO Coprocessor Module is featured with triggering and star triggering functions for PXI. The NI PXIe-7912 module can be used with PXI Vector Signal Transceivers for complex algorithm operations in real-time. The PXIe-7912 PXI FlexRIO Coprocessor Module is offered with 8 single-ended digital input/output channels. The NI PXIe-7912 module can be operated with a nominal output impedance of 50 Ω. The PXIe-7912 module performs with a nominal input impedance of 100K Ω.  The maximum total power of this module is 58 W.

ModelPXIe-7912
ManufacturerNational Instruments
Part Number785173-01
TypePXI FlexRIO Coprocessor Module
FPGA TypeKintex UltraScale KU040
DRAM4 GB
BRAM21 Mbit
FPGA Slices60600
Dimensions7.4 in. × 5.1 in.
Weight6.7 oz.
Warranty2-3 Year Warranty
PXIe-7912 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
