National Instruments PXIe-7915 PXI FlexRIO Coprocessor Module
The PXIe-7915 is a PXI FlexRIO Coprocessor Module. The PXIe-7915 module is manufactured by National Instruments. The part number 785174-01 is assigned to the NI PXIe-7915. The PXIe-7915 module is a part of the FlexRIO modules by National Instruments. The NI PXIe-7915 is programmed with Xilinx Vivado for signal-processing functions. The PXIe-7915 module has a Kintex UltraScale KU060 FPGA with 82920 FPGA slices and 2760 DSP slices. The default timebase of the reconfigurable FPGA is 80 MHz. The NI PXIe-7915 module utilizes LabVIEW software for programming as well.
The National Instruments PXIe-7915 PXI FlexRIO Coprocessor Module is offered with 60 DMA channels and transfers data in the MGT form. The PXIe-7915 module is prepared with a DRAM memory of 4 GB and BRAM of 38 Mbit. The NI PXIe-7915 PXI FlexRIO Coprocessor Module has a physical bus width of 32 bit for the onboard DRAM. The onboard clock rate is 1064 MHz. The PXIe-7915 module can be operated with 3 A current for both 3.3 V and 12 V voltages.
The NI PXIe-7915 FlexRIO Coprocessor Module is introduced with eight channels. Four channels are reserved for the transmitter, while the other four are reserved for the receiver. The PXIe-7915 module can function within the data rate between 500 Mbps to 16.375 Gbps. The NI PXIe-7915 module has DC coupling for the receiver and AC coupling for the transmitter. The National Instruments PXIe-7915 PXI FlexRIO Coprocessor Module has a differential nominal input resistance of 100 Ω.
| Model | PXIe-7915 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 785174-01 |
| Type | PXI FlexRIO Coprocessor Module |
| FPGA Type | Kintex UltraScale KU060 |
| DRAM | 4 GB |
| BRAM | 38 Mbit |
| FPGA Slices | 82920 |
| Dimensions | 7.4 in. × 5.1 in. |
| Weight | 6.7 oz. |
| Warranty | 2-3 Year Warranty |
| PXIe-7915 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
