National Instruments 778926-01 PXI Firewire IEEE 1394 Module
National Instruments part number 778926-01 is an identifying part number for the PXI-8252, a PXI Firewire IEEE 1394 Module from the Frame Grabber series. It has 3 IEEE 1394 camera input ports and works with the Windows operating system. The NI 778926-01 is an OHCI-compliant IEEE 1394 interface that offers a bandwidth of 400 MB per second. It is compatible with Windows 2000, XP, Me, and 98. This module allows users to collect images from IEEE 1394 cameras and includes NI vision acquisition software for image acquisition.
This part number comes with Vision Acquisition Software from the PXI-8252 series. Moreover, this module features three 6-pin female IEEE 1394 connectors and a 32-bit universal signaling PXI connector. It supports both 3.3 V and 5 V signaling at 33 MHz (PXI Vio). The typical power consumption is 140 mA at 3.3 V. The National Instruments 778926-01 IEEE 1394 Interface is fully compatible with software applications like LabVIEW and Measurement Studio, optimizing operational efficiency and accelerating measurement processes.
It adheres to safety standards such as IEC-60068-2-1 and IEC-60068-2-2, certified for indoor use with a pollution degree of 2. For optimal performance, the 778926-01 module should be operated within a temperature range of 32 to 131 °F and with a noncondensing relative humidity ranging from 10 to 90%. When not in use, the device can withstand a wide ranging storage temperature range of -4 to 158 °F with a noncondensing relative humidity range of 5 to 95%.
National Instruments has declared obsolete status for the 778926-01, however, it is still available for purchase and repair services with Apex Waves.
| Part Number | 778926-01 |
|---|---|
| Model Name | PXI-8252 |
| Part Type | PXI Firewire IEEE 1394 Module |
| Series | Frame Grabbers |
| Operating System | Windows |
| Ports | 3 IEEE 1394a camera input ports |
| Power | 12 W of IEEE 1394 bus power divided among 3 ports to power up to 4 cameras |
| Theoretical Maximum Power Consumption | 315 mA at 3.3 V 1.8 A at 5.0 V 400 mA at 12 V |
| Signaling PXI Vio | 3.3 V/5 V (Universal), 33 MHz |
| Dimensions | (6.3 × 3.9 in.), 3U |
