National Instruments NI-1424 Digital Image Acquisition Device
The National Instruments NI-1424 is a monochrome and color PCI-based image acquisition device that supports a diverse range of digital cameras. This model includes the NI-1424 100-stick SCSI-type connector that associates with all advanced video information inputs, computerized empower inputs, camera control outputs, RS-232 serial interface, and the outer trigger signals. To get to these associations, the user can construct their own custom link or utilize one of the discretionary links from National Instruments.
This model also offers a Vision Builder for Automated Inspection feature, which enables the user to effectively arrange and benchmark a succession of visual inspection steps, and in addition deploy the visual examination framework for mechanized examination. With Vision Builder AI, the user can perform effective visual examination tasks and settle on choices in light of the consequences of singular tasks. With Vision Builder AI, the user can move their arranged inspection to LabVIEW, increasing the capacities of their applications if it is essential.
This model can be configured to use four 8-bit or two 10-bit to 16-bit lookup tables (LUTs) to make LUT works like contrast enhancement, data inversion, and a huge variety of nonlinear transfer functions. But that is not all this model has to offer; the NI-1424 enables the user to reorder the data from up to four 8-bit taps, so the data from each tap can be scanned from any direction.
If you are interested in this model and you want to learn more about its options, specifications, and special features, you can read its manual which is available on the ApexWaves.com website.
| Model | NI-1424 |
|---|---|
| Manufacturer | National Instruments |
| Series | Frame Grabbers |
| Type | Digital Image Acquisition Device |
| Channels | 4 |
| Base Memory Configuration | 16 |
| Acquisition Rate | 200 MB/s |
| Warranty | 2-3 Year Warranty |
| NI-1424 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for NI-1424:
National Instruments NI-1424 Frequently Asked Questions
Question: Does the NI 1424 collect images in monochrome or color?
Answer: The NI 1424 collects images in both high-quality monochrome and color.
Question: What do you need to set up and use the NI-1424?
Answer: To set up and use the NI-1424 you need the following: the NI 1424 image acquisition device, a video camera or other video source, D100 series camera cables, depending on your camera, and a computer running Microsoft Windows Vista/XP/2000 with at least one available PCI slot.
Question: What optional equipment can you use with the NI 1424?
Answer: With the NI 1424, other optional equipment you can use includes: D2504 camera cable, a four-pod BNC cable to route trigger signals to a BNC connector block, and memory modules to increase the NI 1424 onboard memory.
