National Instruments PCIe-8244 Frame Grabber Device
The PCIe-8244 (Part Number: 782890-01) Frame Grabber Device can give power to the camera straightforwardly through the USB 3.0 bus. As indicated by the USB 3.0 specifications, the most extreme power that can be provided is 4.5 watts at 5 volts. If there are different gadgets that require a lot of intensity, it is conceivable that there is inadequate power being provided to the camera. For this situation, the user may wish to explore the utilization of a USB 3.0 controlled center. To guarantee that the camera can send information at the appraised speed, it would be ideal if the user guarantees that the USB 3.0 host controller interface and the motherboard bolster PCIe 2.0 information throughput rates, which is adequately 384 MB/s. PCIe 1.0 engineering cannot surpass 180 MB/s, while general PCI bolsters just 133 MB/s.
Ensure that the host controller interface and/or the motherboard bolster rendition 3.0 of the USB standard as opposed to adaptation 2.0. It is conceivable that the USB 3.0 camera is running on USB 2.0, yet at only 480 Mb/s, the throughput of USB 2.0 is fundamentally not as high as USB 3.0. This is a kind of PSE that goes about as transitional and between a non-PoE (conventional) switch and PD by infusing power into the link. Midspans give a simple method for joining PoE into a current system, since the user does not have to supplant any current switches or foundation. PoE Injector is a basic PSE that infuses control into a solitary Ethernet link. The midspan commonly gives capacity to a few Ethernet ports.
| Model | PCIe-8244 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 782890-01 |
| Type | Frame Grabber Device |
| Number of Ports | 4 Ports |
| Speed | 1.5 Mbps, 12 Mbps, 480 Mbps, 5 Gbps |
| Camera Interface | USB3 Vision |
| I/O Connectors | 4 × USB 3.0 connectors |
| PCI Express Compliance | 2.0 |
| Bus Powered | Yes |
| Power Requirements | +12 V, +3.3 V - 0.32 A, 1.8 A |
| Dimensions | 5.47 in. × 2.52 in. |
| Weight | 0.21 lb. |
| Driver Software | NI-IMAQdx 4.1 NI Vision Renesas µPD720202 |
| Warranty | 2-3 Year Warranty |
| PCIe-8244 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCIe-8244:
National Instruments PCIe-8244 Frequently Asked Questions
Question: What type of cameras is the PCIe-8244 best used with?
Answer: The PCIe-8244 is designed to be used with USB3 Vision cameras.
Question: What can I do to set a benchmark of the speeds my camera can reach using the NI PCIe-8244?
Answer: To test out the NI PCIe-8244 device’s speed with one camera, log into an AVI file with just one camera. This will give you a benchmark to see what speeds it can hit.
Question: What type of cable can I use with the PCIe-8244?
Answer: You should use only USB 3.0 cables that are SuperSpeed-certified with the PCIe-8244.
