National Instruments PCI-6552 Digital Waveform Generator
The PCI-6552 (Part Numbers: 778951-01, 778951-02, 778951-03) is an efficient Digital Waveform Generator from National Instruments with 1, 8, or 64 Mb/channel onboard memory. This model has the frequency bandwidth of 100 MHz. The National Instruments PCI-6552 Digital Waveform Generator comes with 20 data channels. These channels have the capability to offer per channel, per cycle, and bidirectional control. There are also three input and two output clock terminals. The instrument offers a resolution of 10 mV for voltage levels. The user can utilize this model for the hardware comparison of advanced electronic equipment.
The National Instruments PCI-6552 Digital Waveform Generator has amazing memory architecture with synchronization and memory core (SMC) technology. This feature permits the user to save the waveform and user-defined parameters in the onboard memory. The instrument has the dimensions of 12.6 x 35.5 in centimeters and weighs around 375 grams. This model comes with the SMB jack connector type for CLK IN, CLK OUT, and PFI 0. It supports connector type 68-pin VHDCI. for digital data and control channels. The NI PCI-6552 Waveform Generator offers support for various drivers and application software, such as NI-HSDIO, LabVIEW, LabWindows, Measurement Studio, MS Visual, and .NET.
The National Instruments PCI-6552 Digital Waveform Generator also includes a MAX option, which is a measurement automation explorer. MAX provides interactive configuration and test tools. The NI-HSDIO enables the user to configure, control, and calibrate the PCI-6552. This model complies to various safety specifications. The NI PCI-6552 Waveform Generator has the typical power consumption of 21.6 watts and the maximum power consumption of 27 watts.
| Model | PCI-6552 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 778951-01, 778951-02, 778951-03 |
| Series | HSDIO Series |
| Type | Digital Waveform Generator |
| Digital I/O Channels | 20 |
| Maximum Data Rate | 100 Mbits/s |
| Memory | 8 or 64 Mb/channel |
| Dimensions | 4.95 in. × 13.9 in. |
| Weight | 13.2 oz. |
| Warranty | 2-3 Year Warranty |
| PCI-6551 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCI-6552:
National Instruments PCI-6552 Frequently Asked Questions
Question: What is the maximum speed on the NI PCI-6552?
Answer: The maximum speed on the NI PCI-6552 is 100 MHz.
Question: What is the strobe frequency range for the NI PCI-6552?
Answer: The strobe frequency range for the NI PCI 6552 is 48 Hz to 100 MHz.
Question: Are the number of samples available for waveform storage user-defined on the PCI 6552?
Answer: Yes, the number of samples (S) available for waveform storage on the PCI 6552 are flexible and user-defined.
Question: What technology is used on the PCI-6552 for the waveforms to operate?
Answer: The PCI-6552 uses the Synchronization and Memory Core (SMC) technology in which waveforms and instructions share onboard memory.
