National Instruments 780055-01 Multifunction I/O Device

National Instruments part number 780055-01 is an identifying part number for the USB-6289, a DIO USB Multifunction I/O Device. The NI 780055-01 has 32 Analog Inputs (18-bit, 526 kS/s), 4 Analog Outputs (2.86 MS/s), and 48 Digital Inputs Outputs. It has cost-effective, dependable data acquisition (DAQ) capabilities, suitable for a wide range of applications, including laboratory automation, research, design verification/testing, and manufacturing testing.

Users can enhance the device with sensor and high-voltage measurement capabilities using SCC or SCXI signal conditioning modules. The included NI-DAQmx driver and configuration utility streamline the process of configuration and measurement. The 780055-01 offers DC input coupling that allows direct current measurements. The input range of this device is adjustable and can accommodate voltages from ±0.1 V to ±10 V, providing flexibility for various signal amplitudes. In terms of sampling rates, it can reach a maximum rate of 625 kS/s for single-channel measurements and 500 kS/s for multichannel measurements when aggregating data from multiple channels.

The NI 780055-01 comes with two versatile counters/timers with a 32-bit resolution, providing precise measurements for Edge Counting, Pulse, and Two-Edge Separation. These counters operate with internal base clocks at frequencies of 80 MHz, 20 MHz, and 0.1 MHz, while also supporting external base clock frequencies ranging from 0 MHz to 20 MHz.

Additionally, the device includes a 10-bit resolution analog trigger with Analog Edge Triggering and Analog Window Triggering modes for enhanced triggering capabilities. This model range comes with multiple variants. Each part has a distinction from other variants in terms of its Supported Power Input and Front Connection Type.

Part Number780055-01
Model NameUSB-6289
Part TypeUSB Malfunction I/O Device
Supported Power InputUnited States 120VAC
Front Connection TypeScrew Terminal
Number of Bidirectional Digital Channels48
Maximum number of Differential Analog Input Channels16
Analog Input FIFO Buffer Size2047 Samples
Bus ConnectorUSB 2.0
Number of Analog Output Channels4
