National Instruments GPIB T7 Fiber-Optic Cable
The NI GPIB T7 (Part Numbers: 182805-010, 182805-020, 182805-030, 182805-050, 182805-100, 182805-200, 182805-500, and 182805-01K) is a Fiber-Optic Cable. The GPIB T7 is also referred to as the GPIB Cable. This cable comes with two 2-pin, male connectors. This cable’s specifications include 62.5/125 um, 850 nm wavelength. The GPIB T7 Cable is specifically designed for the National Instruments GPIB-140A Extender. The conversion of the GPIB signals into optical signals is the best-suited approach for applications where connectivity between far located hardware devices is required.
With this cable, you will be able to achieve GPIB based communication over a maximum distance of 1 kilometer. The National Instruments GPIB T7 Fiber-Optic Cable offers straightforward, point-to-point connectivity, so you won’t need additional hardware or software resources. This cable is available in different lengths to provide link distances from 10 meters to 1000 meters. The high-quality fiber used in the construction of this cable is designed to operate in outside environments.
| Model | GPIB T7 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 182805-010, 182805-020, 182805-030, 182805-050, 182805-100, 182805-200, 182805-500, and 182805-01K |
| Type | Fiber-Optic Cable |
| Cable Length | 10 m, 20 m, 30 m, 50 m, 100 m, 200 m, 500 m, and 1,000 m |
| Back-End Connection | 2-Pin, Male |
| Front-End Connection | 2-Pin, Male |
| Compatible Models | GPIB-140A Extender |
| Warranty | 2-3 Year Warranty |
| GPIB T7 Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
