National Instrument LFH200 Switch Cable
The NI LFH200 (Part Numbers: 779038-01, 779038-02, and 779038-03) Switch Cable is designed to be used with NI Switch Modules that support connectivity through an LFH200 connector. This Switch Cable has a maximum voltage of 60 VDC, CAT I and is available as a 1 meter or 2 meter cable. This Switch Cable is offered in multiple variations, but all versions come with a similar LFH200 Front End Connection.
The first configuration of this cable is known as the SH200LFH-4xDB50F-C (Part Number: 779038-02); it is recommended for use with the SCXI-1169, PXI-2570, or PXI-2571. The second configuration of the LFH200 Switch Cable comes with 25 un-terminated, stripped, and tinned wires at the device-end or application-end. This configuration of the LFH200 Switch Cable is generally known as the SH200LFH-BARE WIRE (Part Number: 779038-01).
The third configuration of this Switch Cable is called SH200LFH-4xDB50F-S (Part Number: 779038-03). This configuration is suitable for the integration of the SCXI-1175 or PXI-2575 into a system.
| Model | LFH200 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 779038-01, 779038-02, and 779038-03 |
| Type | Switch Cable |
| Back End Connection | LFH200 |
| Front End Connection | Bare wire, 4X50-Pin D-SUB |
| Cable Lengths | 1 m or 2 m |
| Compatible Models | SCXI-1169, SCXI-1175, PXI-2569, PXI-2570, PXI-2571, and PXI-2575 |
| Warranty | 2-3 Year Warranty |
| LFH200 Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
Associated part numbers for LFH200:
National Instruments LFH200 Frequently Asked Questions
Question: What is the maximum voltage of the LFH200?
Answer: The maximum voltage of the cable is 60 VDC.
Question: What is the time delay of the Switch Cable?
Answer: The LFH200 has a maximum time delay of 1.60 ns/ft with a max skew of 0.040 ns/ft.
Question: What is the gauge of the LFH200 cable?
Answer: The gauge of the cable is 28 AWG.
Question: What NI modules are the LFH200 cable compatible with?
Answer: Depending on the connection configuration (which differs by part number), the LFH200 is compatible with the SCXI-1169, SCXI-1175, PXI-2569, PXI-2570, PXI-2571, and the PXI-2575
