National Instruments PCI-6034 Multifunction I/O Device
The NI PCI-6034 can filter multi-channels at a high rate from the single-channel rate. Be that as it may, consider the settling times for every one of the boards. The settling time for the PCI-6034 is free of the chosen increase, even at the most extreme examining rate. No additional settling time is important between channels if the gain is steady and source impedances are low. When scanning among channels at different additions, the settling times may increment. When the PGIA changes to a higher gain, the signal on the past channel might be well outside the new, less substantial range.
For example, assume a 4 V signal is associated with channel 0 and a 1 mV signal is associated with channel 1; also, that the PGIA is modified to apply a gain of one to channel 0 and a gain of 100 to channel 1. When the multiplexer changes to channel 1 and the PGIA changes to a gain of 100, the new full-scale run is 100 mV (if the ADC is in unipolar mode). Choosing a bipolar range for a specific DAC implies that any information kept in touch with that DAC will be translated as two’s supplement arrangements. In two's supplement mode, information esteems kept in touch with the simple yield channel can be either positive or negative. If the user selects unipolar range, information is deciphered in straight parallel organization. In straight parallel mode, information esteems kept in touch with the simple yield channel run must be certain.
PCI-6034 End of Life Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.
| Model | PCI-6034 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 778075-01 |
| Series | E Series |
| Type | Multifunction DAQ |
| Analog Input Channels | 16 (16-Bit, 200 kS/s) or 8 differential |
| Digital Input/Output | 8 (TTL/CMOS Compatibility) |
| Timing I/O | 2 Counter/Timer I/O (24 bits, 20MHz ) |
| I/O Connector | 68-pin male SCSI-II type |
| Power Requirements | +5 VDC - 1.5 A |
| Dimensions | 6.9 × 4.2 in. |
| Driver Software | NI-DAQ |
| Warranty | 2-3 Year Warranty |
| PCI-6034E Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCI-6034:
National Instruments PCI-6034 Frequently Asked Questions
Question: What is the driver software for the NI PCI 6034?
Answer: The driver software for the NI PCI 6034 is NI-DAQ 7.
Question: Which signal conditioning accessories can be used with the PCI-6034?
Answer: The SCB-68 Terminal Block, TB-2705 Terminal Block, CB-68LP Terminal Block, SH6868-EP Cable, and R6868 Cable can be used with the PCI-6034.
Question: What is the maximum working voltage of the PCI-6034?
Answer: Every input on the PCI-6034 should stay within ±11 V of ground.
Question: Which types of configuration can be completed on the NI PCI-6034?
Answer: Data acquisition-related and bus-related configuration can be completed on the NI PCI-6034.
