National Instruments PCMCIA-5102 Digitizer
The PCMCIA-5102 is a dual-channel Digitizer. The NI PCMCIA-5102 is produced by National Instruments. The NI PCMCIA-5102 is a Type II PCMCIA card. The PCMCIA-5102 is manufactured with two single-ended analog input channels with substantial functionalities. This Digitizer can be utilized with NI-DAQ and NI-SCOPE driver software. The PCMCIA-5102 can be accessed with the application software of LabVIEW, LabWindows, Visual Basic, and Measurement Studio. The PCMCIA-5102 functions on Windows operating systems.
The NI PCMCIA-5102 is featured with channels that have a bandwidth of 15 MHz per channel. The PCMCIA-5102 can provide a voltage range of ± 50 mV to ± 5 V by using an input software selectable attenuation option. This Digitizer has software-selectable AC and DC input coupling. The PCMCIA-5102 is built with an onboard memory size of 663,000 samples. The National Instruments PCMCIA-5102 provides data access to the onboard memory before transferring to the host computer memory.
The NI PCMCIA-5102 is developed with multiple triggering capabilities like hysteresis values, bi-level triggering for input channels, trigger hold-off, and programmable trigger thresholds. This Digitizer is fabricated with two digital TTL/CMOS triggers to synchronize various modules. The PCMCIA-5102 has an 8-bit resolution analog-to-digital converter (ADC). The NI PCMCIA-5102 has a recommended 15 minute warm-up time before use. This Digitizer should be externally calibrated every year and internally calibrated each time the environmental conditions change.
PCMCIA-5102 Obsolete Status has been announced by National Instruments, but the Digitizer will still be available for purchase and repairs by Apex Waves.
| Model | PCMCIA-5102 |
|---|---|
| Manufacturer | National Instruments |
| Type | Digitizer |
| Input Channels | 2 single-ended, simultaneously sampled |
| ADC Resolution | 8 bits |
| Maximum Sample Rate | 20 MS/s |
| Input Coupling | AC or DC, software-selectable |
| Size | Type II card |
| Warranty | 2-3 Year Warranty |
| PCMCIA-5102 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
