National Instruments PXIe-5630 PXI Vector Network Analyzer

The PXIe-5630 (Part Numbers: 781219-01 and 781219-02) Vector Network Analyzer (VNA) has the following features:

· 10 MHz to 6 GHz frequency range

· >100 dB dynamic range

· <-123 dBm/Hz noise floor

· -30 dBm to +5 dBm power range

· <400 s/point sweep speed over 3,201 points

· Configure Complete PXI System

· Automation precision calibration

The National Instruments PXIe-5630 is designed to address the demands of engineers to integrate the analysis of a vector network into their systems without incurring the costs of regular bench top VNAs. This model is a 2-port VNA that provides exceptional phase noise and sample jitter.

Using its soft front panel which provides a fully-featured interface, the NI PXIe-5630 VNA can be controlled interactively. This model can also be programmed for NI LabVIEW software and NI LabWindows/CVI ANSI C development environments by using APIs.

The NI PXIe 5630 features a frequency resolution of 10 Hz and a power step resolution of 0.5 dB on the port 1 source. For this device, the input impedance is at 50W and the input range is +3 dBm to –10 dBm sine wave. The ambient temperature range of this device is from 0 °C to 55 °C in an operating environment, whereas it is –41 °C to +71 °C in a storage environment. The NI PXIe-5630 VNA is a 3U, two slot, PXI Express module, with dimensions of 8.5 in. × 1.6 in. × 5.1 in. This VNA weighs 24.0 oz.

Model	PXIe-5630
Part Numbers	781219-01 and 781219-02
Manufacturer	National Instruments
Type	PXI Vector Network Analyzer
Sources Supported	1
Maximum Source Power	5 dBm
Frequency Range	10 MHz to 6 GHz
Dimensions	8.5 x 1.6 x 5.1 in.
Weight	24.0 oz.
Warranty	2-3 Year Warranty
PXIe-5630 Manual	User Manual and Maintenance Manual Available for Download
Price	Contact a sales representative for a quote.

Associated part numbers for PXIe-5630:

National Instruments PXIe-5630 Frequently Asked Questions

Question: Which S parameter measurements are supported by the Vector Network Analyzer?

Answer: The NI PXIe-5630 VNA supports S11 and S21 measurements.

Question: Why does the NI PXIe-5630 have two part numbers?

Answer: The two part numbers for the NI PXIe-5630 have the same specifications, but part number 781219-02 supports time domain analysis and part number 781219-01 does not.

Question: Is using the AutoCal more accurate/faster than using the manual calibration kit?

Answer: The AutoCal kit for the PXIe-5630 automates the calibration process, unlike the manual calibration kit. Therefore, the AutoCal kit ensures swifter calibration and a reduced chance for human mistakes.

Question: Which types of connectors are used on the PXIe-5630?

Answer: The PXI VNA uses Type-K, 50 Ohm connectors.
