National Instruments PXI-8531 PXI CANopen Interface Module
The PXI-8531 (Part Number: 781061-01) is a 1-Port CANopen Interface Module, made for creating applications with the NI-Industrial Communications for CANopen controller. CANopen is the application layer that is set on the physical CAN layer normally utilized for modern automated applications. It was intended for control systems of movement-oriented machines, such as taking care of frameworks. However, it is currently utilized as part of various items and applications, including medical equipment, cross-country vehicles, oceanic gadgets, public transport, and construction automation. The NI PXI-8531 can transmit/receive data processing objects (PDOs) and data service objects (SDOs) according to the CiA-DS301. It likewise has a SDO batch editor with EDS file integration and LSS services support for slave node configuration.
The NI PXI 8531 CANopen Interface Module provides a high level API to effortlessly deal with the CANopen system and its gadgets. This total 32 bit driver is intended for use in Windows Vista/XP focal points and continuous LabVIEW focal points like the PXI and NI mechanical controllers. The configuration instruments are integrated in the LabVIEW project to give online access to the system, master and slave gadget parameters. Likewise, CANopen gadget signals are consequently recognized and mapped to move I/O factors, so you can undoubtedly read and write from the I/O of the gadget without an intensive learning of the CANopen protocol.
| Model | PXI-8531 |
|---|---|
| Part Number | 781061-01 |
| Manufacturer | National Instruments |
| Type | PXI CANopen Interface Module |
| Ports | 1 |
| Nonvolatile Memory | 16 Mbit |
| SRAM | 256 MB |
| Transceiver | NXP PCA82C251 High-Speed CAN transceiver |
| LEDs | 2 |
| Warranty | 2-3 Year Warranty |
| PXI-8531 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXI-8531:
National Instruments PXI-8531 Frequently Asked Questions
Question: What is the size of the FPGA block memory on the NI PXI-8531?
Answer: The NI PXI-8531 has an FPGA block memory size of 92 Kbit.
Question: What type of media storage is available on the PXI-8531?
Answer: The PXI-8531 does not have media storage.
Question: How many ports does the PXI-8531 have?
Answer: The PXI-8531 has 1 port.
