PXI-8155B National Instruments PXI Controller | Apex Waves | Image
PXI-8155B National Instruments PXI Controller | Apex Waves | Image
PXI-8155B New
PXI-8155B Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

PXI-8155B National Instruments PXI Controller | Apex Waves | Image
PXI-8155B National Instruments PXI Controller | Apex Waves | Image
PXI-8155B New
PXI-8155B Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments PXI-8155B PXI Controller

The National Instruments PXI-8155B is a CompactPCI-compatible system controller that is fully compatible with the PXI bus specifications. Well suited for industrial applications, this model comes equipped with a comprehensive range of standard I/O features, including: a 3.5 in. 1.44 MB floppy drive, 1 4 GB hard drive, Super VGA with 2 MB SGRAM, 1 IEEE 1284 parallel port, 1 serial port, 1 PS/2 keyboard and mouse, and 1 USB port.

The NI PXI-8155B is designed to interface directly to the PXI-1020 and PXI-1025 chassis. As a result, this interface provides the signals required to control an IDE device, a TFT LCD, a PS/2 keyboard, and mouse. By type, the NI PXI-8155B is a modular PC sized in PXI 3U form factor, which comes equipped with various peripherals that generally require add-in cards on PCs. The PCI video circuitry incorporated in this Embedded Controller has a 64-bit data path and supports Windows 98 dual display: CRT and LCD.

The PXI-8155B also has a BIOS/RTC block that contains the Real Time Clock Interface and the boot BIOS. To provide the user with optimum video performance, this model incorporates the S3 Virge/MX Series chip family- a combination of RAMDAC and graphics accelerator with TFT LCD support. The chip utilized in this Controller is compatible with the S3 video driver, as well as Microsoft Windows video driver. With this model, the user will be able to use any monitor with 50 kHz of horizontal and 60 Hz vertical scan rate.

PXI-8155B Obsolete Status has been announced by National Instruments, but the Controller will still be available for purchase and repairs by Apex Waves.

ModelPXI-8155B
ManufacturerNational Instruments
TypePXI Controller
CPU233 MHz MMX or 333 MMX Processor
Hard Drive4 GB minimum
Maximum SDRAM256 MB
Front-Panel LEDs2
Dimensions3.2 x 5.1 x 8.5 in.
Weight2.4 lb.
Warranty2-3 Year Warranty
PXI-8155B ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PXI-8155B:

National Instruments PXI-8155B Frequently Asked Questions



Question: What does the PXI-8155B utilize for peripheral expansion?



Answer: For peripheral expansion, the PXI-8155B utilizes the PCI local bus and the ISA bus.



Question: Which Chassis can the NI PXI-8155B interface with?



Answer: The NI PXI-8155B can interface with the PXI-1020 and PXI-1025 Chassis.



Question: What are the slot requirements for the PXI-8155B?



Answer: The PXI-8155B requires one system slot and three controller expansion slots.



Question: Does the NI PXI-8155B have a keyboard and mouse connector?



Answer: Yes, the NI PXI-8155B has a keyboard and mouse connector, as well as several other front panel connectors.
