National Instruments PXIe-4113 PXI Programmable Power Supply

The National Instruments PXIe‑4113 (Part Number: 782857-02) is a 2-Channel, 10 V, 6 A PXI Programmable DC Power Supply with isolated outputs. This module simplifies the process of designing automated test systems for a wide range of applications, such as aerospace, defense, automotive, and component test by eradicating the need to mix multiple instrumentation form factors in a given test rack. The PXIe-4113 is a single-quadrant power supply with two output channels that are capable of identical output. The power supply’s channels are isolated from each other and from chassis ground​.

This PXI power supply module features standard output disconnect functionality, which allows isolation from the device under test (DUT) when not in use, as well as remote sense to correct for losses in the system wiring​. The NI PXIe-4113 supplies programmable DC power for applications such as characterization, design validation, and manufacturing test.

The PXIe-4113 has a DC voltage range of 0 V to 10 V and a minimum programmable voltage level/limit of 0.03 V. The DC current range is 0 A to 6 A, and the minimum programmable current level is 0.02 A. This model’s maximum output power is 60 W per channel, for a total output power of 120 W. For auxiliary power input line regulation, the voltage variation is 0.2 mV and the current variation is 0.5 mA​.

The NI PXIe‑4113 supports a maximum output lead drop of 1 V per lead and a maximum sense lead resistance of 1 Ω per lead. For random vibration, the operating range is 5 Hz to 500 Hz at 0.3 grms, and the non-operating range is 5 Hz to 500 Hz at 2.4 grms, tested in accordance with IEC 60068-2-64.

ModelPXIe-4113
Part Number782857-02
ManufacturerNational Instruments
TypePXI Programmable DC Power Supply
Channels2 Isolated Output Channels
Total Output Power120 W (60 W per channel)
Voltage/Current Range0 to 10 V / 0 to 6 A
Min Programmable Voltage / Current0.03 V / 0.02 A
Dimensions (W x H x D)8.5 x 0.8 x 5.1 in.
Weight15.6 oz. (443 g)
Warranty2-Year Calibration Interval Recommended
ManualUser Manual and Specifications Available for Download

Associated part numbers for PXIe-4113:

National Instruments PXIe-4113 Frequently Asked Questions



Question: What is the maximum current of the PXIe-4113?

Answer: The maximum current of the PXIe-4113 is 6 A.



Question: Does the PXIe-4113 include auxiliary power?

Answer: Yes, the PXIe-4113 includes auxiliary power.



Question: How many quadrants does the NI PXIe-4113 have?

Answer: The NI PXIe-4113 has 1 quadrant.



Question: What types of input triggers can the PXIe-4113 perform?

Answer: The PXIe-4113 can perform Measure, Start, Sequence Advance, and Source triggers.
