PCIe-7857R National Instruments Multifunction Reconfigurable I/O Device | Apex Waves | Image
PCIe-7857R National Instruments Multifunction Reconfigurable I/O Device | Apex Waves | Image
PCIe-7857R New
PCIe-7857R Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

PCIe-7857R National Instruments Multifunction Reconfigurable I/O Device | Apex Waves | Image
PCIe-7857R National Instruments Multifunction Reconfigurable I/O Device | Apex Waves | Image
PCIe-7857R New
PCIe-7857R Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments PCIe-7857R Multifunction Reconfigurable I/O Device

The PCIe-7857R is a Multifunction Reconfigurable I/O Device. The PCIe-7857R device is developed by National Instruments. The NI PCIe-7857R is a member of the R Series offered by NI. The PCIe-7857R is released with the part number 786458-01. The PCIe-7857R is used for multifunction purposes. The NI PCIe-7857R can be customized using the LabVIEW FPGA Module for multiple applications.

The NI PCIe-7857R Multifunction Reconfigurable I/O Device has been assembled with a reconfigurable FPGA. The FPGA is a Kintex-7 160T FPGA that features 11,700 kbits of embedded block RAM. The PCIe-7857R Multifunction Reconfigurable I/O Device features a dedicated ADC for every channel to provide independent timing and triggering facilities. The PCIe-7857R offers an additional advanced feature of multirate sampling.

The National Instruments PCIe-7857R Multifunction Reconfigurable I/O Device has been designed with 8 analog input and 8 output channels. The NI PCIe-7857R is prepared to control input/output signals. The PCIe-7857R has 48 bidirectional digital input/output channels with 1 MS/s maximum channel sampling rate. The PCIe-7857R Multifunction Reconfigurable I/O Device is fabricated with 512 MB of DRAM memory. The NI PCIe-7857R is used with PCI Express x4, x8, and x16 bus connectors. The PCIe-7857R Multifunction Reconfigurable I/O Device is offered with a slew rate of 10 V/us. The PCIe-7857R comes with two 68-pin VHDCI input/output connectors. This device has a maximum clock rate of 80 MHz. The NI PCIe-7857R is similar to the PCIe-7856R, but the PCIe-7857R is an enclosed device.

ModelPCIe-7857R (PCIe-7857)
ManufacturerNational Instruments
Part Numbers786458-01, 147351-04L
SeriesR Series
TypeMultifunction Reconfigurable I/O Device
Bus ConnectorPCI Express
Bidirectional Digital Channels48
FPGAKintex-7 160T
Maximum Sample Rate1 MS/s
EnclosedYes
Maximum Clock Rate80 MHz
Dimensions6.60 x 4.38 in.
Weight1 lb.
Warranty2-3 Year Warranty
PCIe-7857R ManualUser Manual and Maintenance Manual Available for Download
PricingContact a Sales Representative for a quote.
