National Instruments PXIe-7858 PXI Multifunction Reconfigurable I/O Module
The National Instruments PXIe-7858 (Part Numbers: PXIe-7858R and 784147-01) is a Multifunction Reconfigurable I/O Module featured with a Kintex-7 325T FPGA and 512 MB DRAM. This model offers 8 Analog Input/Output Channels and 48 Digital Input/Output channels. The NI PXIe-7858 module can acquire samples at the rate of 1 MS/s. This model supports DIFF, NRSE, and RSE (software-selectable) input modes. The input signal range is ±1 V, ±2 V, ±5 V, ±10 V. This module operates at ±5 nA input bias and input offset current.
The PXIe 7858 provides overvoltage protection. On the analog input channels, the default settings are ±42 V maximum for the powered-on state and ±35 V maximum for the powered-off state. This module has an output range of ±10 V and supports DC output coupling and additional protection. "Short circuit to the ground" is also provided for its analog outputs. The overvoltage protection settings on the outputs are ±15 V maximum for the powered-on state and ±10 V maximum for the powered-off state.
This Multifunction Reconfigurable I/O Module offers a user-configurable power-on state for all of the analog and digital I/Os. As far as its dynamic characteristics are concerned, this module offers 10 V/µs slew rate and ±10 mV for 3 µs glitch energy at midscale transition. The National Instruments PXIe-7858 can provide 5V output within a range of 4.75 V to 5.1 V and 0.5 at maximum output current, with ±30 V overvoltage and 650 mA overcurrent protection.
| Model | PXIe-7858 |
|---|---|
| Part Numbers | PXIe-7858R and 784147-01 |
| Manufacturer | National Instruments |
| Type | PXI Multifunction Reconfigurable I/O Module |
| FPGA | Kintex-7 325T |
| Maximum Sample Rate | 1 MS/s |
| Analog Input Channels | 8 |
| Dimensions | 7.3 x 6.8 x 1.4 in. |
| Weight | 6.02 oz. |
| Warranty | 2-3 Year Warranty |
| PXIe-7858 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXIe-7858:
National Instruments PXIe-7858 Frequently Asked Questions
Question: What are the digital I/O logic levels for the PXIe-7858?
Answer: The digital I/O logic levels for the PXIe-7858 are 1.2V, 1.5V, 1.8V, 2.5V, 3.3V.
Question: What type of ADC do the analog input channels on the NI PXIe-7858 module have?
Answer: The NI PXIe-7858 module has a successive approximation register (SAR) ADC.
Question: What is the minimum I/O pulse width of the PXIe-7858?
Answer: The minimum I/O pulse width of the PXIe-7858 is 6.25 ns.
Question: How many DMA channels does the NI PXIe 7858 have?
Answer: The NI PXIe 7858 has 16 DMA channels.
