National Instruments RMX-4125 Programmable Power Supply Device
The RMX-4125 is a Programmable Power Supply Device. The NI RMX-4125 is designed by National Instruments. The RMX-4125 is delivered with the part number 784766-01. National Instruments fabricates the NI RMX-4125 with multiple displaying qualities and functions. The RMX-4125 is available with the RMX-412x Series of Programmable Power Supply Devices by National Instruments. The RMX-4125 is offered with a total output power of 1500 W.
The National Instruments RMX-4125 Programmable Power Supply Device is prepared with DC power outputs and has rack-mount capability. The NI RMX-4125 device can function with a maximum of 0 to 80 VDC voltage range and 0 to 56 Amperes current range. The RMX-4125 Programmable Power Supply Device is manufactured with multiple displaying functions, such as current, voltage, power, accuracy, and operation displays with LEDs. The NI RMX-4125 Programmable Power Supply Device is composed with protection functions like overvoltage, overcurrent, under-voltage, overheating, and fan failure protection.
The NI RMX-4125 Programmable Power Supply Device comes equipped with various special features for voltages like output voltage control (VPGM), output current control (IPGM), and indicating alarm controls. The National Instruments RMX-4125 Programmable Power Supply Device utilizes multiple interfaces including USB, LAN, and RS-232C. The NI RMX-4125 device is available with line and load regulations of ±10 mV. The RMX-4125 device has a rise time of 100 ms in both rated-load and no-load conditions. The RMX-4125 device is built with a fall time of 100 ms at rated-load, while it is 800 ms at the no-load position.
| Model | RMX-4125 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 784766-01 |
| Type | Programmable Power Supply Device |
| Total Output Power | 1500 W |
| Analog Output Voltage Range | 0 V to 80 V |
| Maximum Current | 56 A |
| Rack Height | 1U |
| Rack Width | Full |
| Weight | 20.94 lb. |
| Warranty | 2-3 Year Warranty |
| RMX-4125 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for RMX-4125:
RMX-4125 PDF Manuals
RACK-MOUNT-PROGRAMMABLE-POWER-SUPPLIES-AND-LOADS-PRODUCT-FLYER.PDF
RMX-4120-4121-4122-4123-4124-4125-4126-4127-LETTER-OF-VOLATILITY.PDF
RMX-PROGRAMMABLE-POWER-SUPPLIES-SAFETY-INFORMATION-AND-INSTALLATION-GUIDE.PDF
RMX-PROGRAMMABLE-POWER-SUPPLIES-USER-MANUAL-AND-SPECIFICATIONS.PDF
