National Instruments USB-6216 Multifunction I/O Device
The USB-6216 (part numbers: 780108-01, 780170-01, 781004-01, 780172-01, and 197504-01) is a Multifunction I/O Device from the National Instruments M Series. Designed for a wide range of test and measurement applications, the NI USB-6216 device is an excellent choice for academic labs, data acquisition, portable data logging, instrument design and testing, and more. Compact and portable, this device features 16 single ended analog input channels that can be configured as 8 differential channels. These channels feature a sampling frequency of 400 kS/s, and the device has 16 bits of ADC resolution. In addition, 2 analog output channels and 32 bidirectional I/O channels provide enhanced connectivity options.
There are a few variations of the NI USB-6216 Multifunction I/O Device, each represented by a unique part number. Part numbers 197504-01 and 780172-01 both describe OEM (Original Equipment Manufacturer) versions of the device, with 780172-01 representing when the device is purchased in a pack of ten. The other part numbers differ in their connectivity options. Part number 780108-01 of the device has screw terminal connectors, part number 781004-01 utilizes BNC connectors, and part number 780170-01 is built with SCSI terminal connections.
The two general purpose timer/counters of the NI USB-6216 feature 32 bits of resolution. The maximum internal base clock frequency for the timers is 80 MHz, and the device provides a frequency generator channel that boasts base clocks of both 10 MHz and 100 kHz. Designed to withstand 60 VDC of continuous voltage between the channel and earth ground, the NI USB-6216 is capable of withstanding an overvoltage of up to 1,000 Vrms between the channel and earth ground for 5 seconds.
The physical dimensions and weight of the NI USB-6216 I/O Device differs depending on the connector type. With a BNC connector type, the device measures 23.5 cm × 11.2 cm × 6.4 cm (9.25 in. × 4.40 in. × 2.50 in.) and weighs 950 g (33.5 oz). With SCSI terminal connectors, the device measures 19.3 cm × 9.4 cm × 3.1 cm (7.61 in. × 3.68 in. × 1.20 in.) and weighs 231 g (8.1 oz). Finally, with Screw Terminal connectors, the USB-6216 device measures 16.9 cm × 9.4 cm × 3.1 cm (6.65 in. × 3.70 in. × 1.20 in.) and weighs 206 g (7.2 oz).
| Model | USB-6216 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 780108-01, 780170-01, 781004-01, 780172-01, 197504-01 |
| Type | Multifunction I/O Device |
| Analog Input Channels | 8 differential or 16 single-ended |
| Maximum Sample Rate | 400 kS/s |
| Analog Input Resolution | 16 bits |
| Connector Type | Screw Terminal, SCSI, or BNC |
| Dimensions | BNC: 9.25 in. × 4.40 in. × 2.50 in. Mass Termination: 7.61 in. × 3.68 in. × 1.20 in. Screw Terminal: 6.65 in. × 3.70 in. × 1.20 in. |
| Weight | BNC: 33.5 oz. Mass Termination: 8.1 oz. Screw Terminal: 7.2 oz. |
| Warranty | Three Year Warranty |
| USB-6216 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for USB-6216:
National Instruments USB-6216 Frequently Asked Questions
Question: What is the current limit protection of the USB-6216?
Answer: The Multifunction I/O Device has current protection of ±10 V.
Question: How often should the USB-6216 be calibrated?
Answer: It is recommended to calibrate the device once a year.
Question: What type of I/O connector does the device have?
Answer: The different part numbers of the USB-6216 have different I/O connectors. The BNC version of the device (781004-01) has 19 BNCs and 26 screw terminals, the mass termination version (780170-01) has a 68-pin SCSI connector, and the screw terminal (780108-01) version features four 16-position combicon
