VXI-1500 National Instruments VXI Mainframe | Apex Waves | Image
VXI-1500 National Instruments VXI Mainframe | Apex Waves | Image
VXI-1500 New
VXI-1500 Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

VXI-1500 National Instruments VXI Mainframe | Apex Waves | Image
VXI-1500 National Instruments VXI Mainframe | Apex Waves | Image
VXI-1500 New
VXI-1500 Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments VXI-1500 VXI Mainframe

The VXI-1500 is a VXI Mainframe produced by National Instruments. The NI VXI-1500 contains a backplane with 13 slots and a high-output power supply. The VXI-1500 is made with a structural design that renders optimization tools for maximum use in multiple applications. The VXI-1500 Mainframe is compatible with the VXIbus Specification Revision 1.4.

This VXI Mainframe has a low mean time to repair (MTTR), since it has a high level of maintainability. The NI VXI-1500 is built with 13 C-sized VXIbus slots. The VXIbus slots can also fit A-sized and B-sized modules if adapters are used. The NI VXI-1500 is designed without backplane jumpers. The VXI-1500 uses 1100 W of heat dissipation through filtered forced-air cooling. This VXI Mainframe has 1100 W (115 VAC input) or 1420 W (230 VAC input) power.

The NI VXI-1500 is manufactured with universal AC input, which means the mainframe can utilize auto-voltage as well as auto-frequency ranging. The NI VXI-1500 has overcurrent protection through push-reset circuit breakers. The VXI-1500 is equipped with a removable power supply with a MTBF of 50,000 hours. There is a remote power monitoring and inhibit through a back-panel connector as well. An On/Off switch on the front panel allows for simple access and is recessed to stop accidental switching. This VXI Mainframe has two configuration options; it can be rackmounted or installed on a bench.

VXI-1500 Obsolete Status has been announced by National Instruments, but the mainframe will still be available for purchase and repairs by Apex Waves.

ModelVXI-1500
ManufacturerNational Instruments
TypeVXI Mainframe
Slots13
SizeC-size
Per Slot Cooling Capacity85 W
Input Voltage Range85 to 264 VAC
Input Frequency Range47 to 500 Hz
Over-Current Protection15 A circuit breaker
Dimensions15.45 in. x 17.20 in. x 28.02 in.
Weight62 lb. (without modules)
Warranty2-3 Year Warranty
VXI-1500 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
