National Instruments VXI-8360T Remote Control Module for VXI
The NI VXI-8360T (Part Number: 780143-01) Remote Control Module is a Slot 0-capable, VXIbus device that can be inserted in any D-size or C-size mainframe. The basic function of this Remote Control Module is to connect a PCI express-enabled host computer to the VXIbus. This communication is achieved over the NI MXI-Express x1 interface.
The MXI-Express link enables the computer to perform like it is directly plugged into the VXI backplane. Thus, the VXI-8360T provides the user with the capabilities of an embedded computer. Through an MXI-Express x1 link, the user can control a VXI backplane with a PCIe or an ExpressCard-based laptop/PC or mobile host adaptor. Furthermore, this system allows the user to physically separate their automation or measurement from the host laptop or PC. With the help of the NI VXI-8360T, the user can combine CompactPCI Express, VXI, PCI Express, CompactRIO, PXI, and PXI Express devices into the same system.
The National Instruments VXI-8360T comes with an advanced set of functionalities. Through this module, the user can achieve an extension of backplane triggers between multiple chassis through one of the multiple front panel connectors provided. This model comes equipped with eight front panel status LEDs: FAILED, SYSFAIL, ONLINE, ACCESS, CB, ACT, PWRGD, and LINK. Additionally, a separate CABLE STATUS LED is provided to indicate whether the cable connections to the ports are healthy or not. The default factory configuration of the NI VXI-8360T forces the module to supply a CLK10 from an integrated oscillator (only if it is plugged into Slot 0).
| Model | VXI-8360T |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 780143-01 |
| Type | Remote Control Module for VXI |
| Slot Requirements | Single VXI C-size slot |
| Compatibility | Fully compatible with VXI specification |
| Size | C size, C-1 |
| Dimensions | 9.2 × 13.4 in. |
| Weight | 46.8 oz. |
| Warranty | 2-3 Year Warranty |
| VXI-8360T Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for VXI-8360T:
National Instruments VXI-8360T Frequently Asked Questions
Question: Which types of front panel I/O connectors are on the NI VXI-8360T?
Answer: The NI VXI-8360T has an EXT CLK SMB connector, a TRIG IN SMB connector, a TRIG OUT SMB connector, an MXI-Express x1 connector, and two TRIG/CLK ports.
Question: What is the maximum trigger bus length of the two TRIG/CLK ports on the VXI-8360T?
Answer: The maximum trigger bus length of the two TRIG/CLK ports on the VXI-8360T is 19 m of cables.
Question: Which driver software is used with the NI VXI-8360T?
Answer: NI-VXI and NI-VISA driver software can be used with the NI VXI-8360T.
Question: What is the absolute maximum DC current of the EXT CLK SMB connector on the VXI-8360T?
Answer: The absolute maximum DC current of the EXT CLK SMB connector on the VXI-8360T is ±50 mA.
