PCIe-6374 National Instruments Multifunction I/O Device | Apex Waves | Image
PCIe-6374 National Instruments Multifunction I/O Device | Apex Waves | Image
PCIe-6374 New
PCIe-6374 Refurbished
❮ ❯

Actual item may vary if no part number is provided on quote request.

PCIe-6374 National Instruments Multifunction I/O Device | Apex Waves | Image
PCIe-6374 National Instruments Multifunction I/O Device | Apex Waves | Image
PCIe-6374 New
PCIe-6374 Refurbished

✔ 2 Year Warranty Included

✔ Free Ground Shipping

✔ NIST Calibration Available

Please fill out the form below to send in your quote request and a representative will contact you with a formal quote. View blog post on Model Name vs. Part Numbers

+Add more parts

Avg. Response Time: 15 min

Prefer to send a text message?

Text your name, e-mail, and parts to quote to:   1-919-809-5227

National Instruments PCIe-6374 Multifunction I/O Device

The PCIe-6374 (Part number: 785817-01) is a high-performance Multifunction I/O Device from National Instruments. This device incorporates a PCI Express Bus Connector. The NI PCIe-6374 offers the flexibility to sample the data simultaneously across all channels. This model has a sampling rate of 3.57 MS per second. This value of sampling rate is based per channel. The device comes with four analog input channels. These channels are differential. The NI PCIe-6374 Multifunction I/O Device additionally has two analog output channels.

The NI PCIe-6374 device comes with a built-in ADC, which has a resolution of sixteen bits. The normal warm-up time of the device is fifteen minutes. The recommended calibration interval for the PCIe 6374 device is a time span of two years. The module is a small device and has a minimal weight. The physical dimensions are 6.60 inches x 4.38 inches. The NI PCIe 6374 Multifunction I/O Device weighs around 110 grams.

The NI PCIe-6374 Multifunction I/O Device includes four counters. These counters have a 32 bit resolution. The counters enable the user to implement the mechanism for triggering requirements. This device includes both analog and digital triggering capabilities. The NI PCIe-6374 Multifunction I/O Device also comes with the DAQ Express software. This software enables the users to complete various measurements and analysis procedures with ease. The instrument can be used for a wide range of applications at the industrial level, which includes manufacturing and testing requirements for different types of telecom equipment.

ModelPCIe-6374
ManufacturerNational Instruments
Part Numbers785817-01
SeriesX Series
TypeMultifunction I/O Device
Analog Input Channels4 (16-Bit, 3.571 MS/s)
Analog Output Channels2 (16-Bit, 3.3 MS/s)
Digital Inputs16
Digital Outputs8
Timing I/O4 Counter/Timer I/O (32 bits, 100 MHz)
Frequency Generator Channels1
Phase-Locked Loop (PLL)1
I/O Connector68-Pos Right Angle Single Stack PCB-Mount VHDCI (Receptacle)
Power Requirements+3.3 V, +12 V -- 1 A, 4.0 W, 13.2 W
Dimensions6.60 in. × 4.38 in.
Weight0.24 lb.
Driver SoftwareNI-DAQmx 9.0
Warranty2-3 Year Warranty
PCIe-6374 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PCIe-6374:

National Instruments PCIe-6374 Frequently Asked Questions



Question: What software is included with the PCIe-6374?

Answer: The PCIe-6374 comes with DAQExpress™ companion software and NI‑DAQmx driver.



Question: How many counters come with the NI PCIe-6374 device?

Answer: The NI PCIe-6374 device comes with four 32-bit counters.



Question: What input would I use to receive an external pulse for the PCIe-6374?

Answer: If you want to receive an external pulse while using the PCIe-6374, as long as the external pulse is 5V digital logic you can wire it to any available PFI terminal.

Accessory TypeModel NamePart Number
CableSHC68-68-EPM192061-01 (1 m)
192061-02 (2 m)
192061-05 (5 m)
192061-0R5 (0.5 m)
RC68-68187252-01 (1 m)
187252-0R25 (0.25 m)
187252-0R5 (0.5 m)
Shielded Connector BlockSCB-68A782536-01
Shielded BNC ConnectorBNC-2110777643-01
Rack-Mountable AccessoryBNC-2090A (Rackmount)779556-01
Terminal BlockTB-2706779183-01
Connector BlockTBX-68777141-01
CB-68LP (Vertical Mount)777145-01
CB-68LPR (Right Angle Mount)777145-02
---

*This device does not support SCC Carriers, and only supports differential (DIFF) input mode.
