National Instruments PXIe-6365 PXI Multifunction I/O Module
The PXIe-6365 (Part Number: 783633-01) is an advanced Multifunction I/O Module from National Instruments with 72 differential analog input channels. The NI PXIe-6365 module can also offer 144 single-ended channels. This module has a built-in ADC with the resolution of 16 bits. There are different sample rates available for different modes of operation, such as 2 MS per second for a single channel and 1 MS per second for the multichannel mode of operation. The NI PXIe-6365 Multifunction I/O Module also implements DC input coupling. The NI PXIe-6365 Module weighs around 203 grams.
The NI PXIe-6365 module has a CMRR value of 100 dB. The instrument exhibits amazing static characteristics. It comes with 24 static channels. The user can program each terminal. This module offers the flexibility to program each terminal as either an input or output. It also includes a ground reference. The typical value for pull-down resistance is 50 kilo-ohms. The NI PXIe-6365 Multifunction I/O Module has an input voltage protection scheme for the voltage range of ± 20 volts, up to two pins.
The NI PXIe-6365 Multifunction I/O Module has a decent FIFO memory with the capability to store as many as 255 samples. The size for the output FIFO, on the other hand, is 2047 samples. It comes with the resolution of 32 bits. The instrument also offers a port or sample size of 8 bits for waveform generation. It makes use of port 0 for the generation of waves.
| Model | PXIe-6365 |
|---|---|
| Part Number | 783633-01 |
| Manufacturer | National Instruments |
| Type | PXI Multifunction I/O Module |
| Single-Ended Analog Input Channels | 144 |
| Differential Analog Input Channels | 72 |
| Maximum Sample Rate | 2 MS/s |
| Board Dimensions | Standard 3U PXI |
| Weight | 7.2 oz. |
| Warranty | 2-3 Year Warranty |
| PXIe-6365 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXIe-6365:
National Instruments PXIe-6365 Frequently Asked Questions
Question: What is the multichannel maximum sample rate for the PXIe-6365?
Answer: The multichannel maximum sample rate for the PXIe-6365 is 1 MS/s.
Question: How many analog triggers does the NI PXIe-6365 have?
Answer: The NI PXIe-6365 has 1 analog trigger.
Question: What is the maximum update rate for two channels on the PXIe-6365?
Answer: The maximum update rate is 2.00 MS/s for two channels on the PXIe-6365.
Question: What is the FIFO size of the NI PXIe-6365?
Answer: The NI PXIe-6365 has an input FIFO size of 255 samples and an output FIFO size 2,047 samples.
PXIe-6365 PDF Manuals
DAQ-GETTING-STARTED-GUIDE-FOR-PXI-PXI-EXPRESS.PDF
DAQ-GETTING-STARTED-READ-ME-FIRST-NI-DAQMX-AND-DAQ-DEVICE-INSTALLATION-GUIDE.PDF
NI-62XX-63XX-PINOUT-LABELS-FOR-THE-SCB-68-NOTE-TO-USERS.PDF
NI-62XX-63XX-PINOUT-LABELS-FOR-THE-SCB-68A-NOTE-TO-USERS.PDF
NI-6345-6355-6365-6375-SAFETY-ENVIRONMENTAL-AND-REGULATORY-INFORMATION.PDF
NI-6365-DEVICE-SPECIFICATIONS.PDF
